Mini circuit breaker, QO, 16A, 3 pole, 240/415VAC, 3kA, bolt on mount | Mayer Electric

SQUARE D . SQDQOBXD316

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 16A, 3 pole, 240/415VAC, 3kA, bolt on mount | Mayer Electric
UPC3606486146163
Weight0.390
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Mini-circuit-breaker-QO-16A-3-pole-240-415VAC-3kA-bolt-on-mount-SQDQOBXD316
jsonUrlData2d05d0149-39fb-46e4-b6e4-aeea00577041
length_AttribDepth
moq, multiple, tierMinQty11
MPN, SKUSQDQOBXD316
qtyInStock0
tierPrice1272.64
width57.0
width_AttribWidth
Circuit Breaker Applicationnot rated
Circuit Breaker Typestandard
Mounting Modebolt-on
Range Of ProductQO
Poles Description3P
Electrical Connectionpressure plate
Line Rated Current16 A
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage240/415 V AC
Warranty18 months
Height76 mm
Breaking CapacityIcu 3 kA 240/415 V AC 50/60 Hz IEC 947-2 || Ics 10 kA
Tightening Torque5-5 N.m 10-25 mm? (AWG 8...AWG 2)
Number Of Spaces Required3
Width57 mm
Depth74 mm
Net Weight0.390 kg
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Product CertificationsIEC
Ambient Air Temperature For Operation40 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDQOBXD316111 @ $272.64
