FUJI ELECTRIC, 460V AC, 75 hp Max Output Power, Variable Frequency Drive - 4UAK3|FRN075F1S-4U - Grainger

Variable Frequency Drive, Input Voltage 460V AC, Input Phase AC Three, Input Frequency 50/60 Hz, Maximum Output Power 75 hp, Maximum Output Current 105 A, Output Voltage 480V AC, Output Phase AC Three, Output Frequency Range 0.1 to 120 Hz, Enclosure Rating NEMA 1

FUJI ELECTRIC . FRN075F1S-4U

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandFUJI ELECTRIC
DimensionUnitinch
HazmatFalse
Extra Product NameFUJI ELECTRIC, 460V AC, 75 hp Max Output Power, Variable Frequency Drive - 4UAK3|FRN075F1S-4U - Grainger
height21.6875
height_AttribOverall Height
length10.5625
length_AttribOverall Depth
moq, multiple, tierMinQty11
MPN, Mfr Model?, Manufacturer Part NumberFRN075F1S-4U
qtyInStock0
SKU, Item?4UAK3
tierPrice15476.95
width13.9375
width_AttribOverall Width
Enclosure RatingNEMA 1
Maximum Output Power75 hp
Input Voltage460V AC
Input Phase AC, Output Phase ACThree
Input Frequency50/60 Hz
Output Voltage480V AC
Output Frequency Range0.1 to 120 Hz
Maximum Output Current105 A
With Bypass / No BypassNo Bypass
With Line Contactor / No Line ContactorNo Line Contactor
Start/Stop ControlProgrammable
ApplicationHV AC
EnclosureOpen
Overall Depth10-9/16 in
Overall Height21-11/16 in
Overall Width13-15/16 in
Display TypeLCD, LED
Control MethodVariable Frequency Control
StandardsUL508C, C22.2 No.14, EN50178-1997
Accepts Input Control SignalRemote Contact
Adjustable Acceleration Time, Adjustable Deceleration Time0 to 3600 sec
Brake Chopper Included, Ethernet Port IncludedNo
ColorBlue
Control TypeKeypad, Remote
Digital ReadoutOutput Frequency, Output Current, Output Voltage
DisplaysMotor Speed With Percent, Alarm Code, Menu, Function Code
Dynamic BrakingYes
Input Type, Output TypeAnalog; Digital
Input Voltage Range380V-480V AC +10% / -15%
Number of Inputs(7) Digital; (3) Analog
Number of Outputs(5) Digital; (2) Analog
Output Voltage Range0V - 460V AC
ProtectionDrive Thermal Overload; Motor Thermal Overload; Over breaking; Overvoltage; Phase Failure; Phase to Phase or Phase to Ground Short Circuit; Under voltage
Starting Torque, Torque @ 1 Hz50%
StyleHeat Sink
Torque ApplicationVariable Torque
SeriesFRENIC - Eco
UNSPSC26111503
Country of OriginVaries

Distributor offers

SellerSKUMOQIn stockMultiplePrices
Grainger4UAK3111 @ $5476.95
ZoroG2353788111 @ $4515.99
RadwellFRN075F1S-4U11
Raptor SuppliesAD9QBA111 @ $6731.64
Allied Electronics7207947911
Dealers ElectricFRN075F1S-4U1Backordered11 @ $5004.69
GuardianFRN075F1S-4U1-211 @ $7025.00
us.rs-online.com72079479111 @ $6045.89
GalcoFRN075F1S-4U-FUIC111 @ $5497.83
