Mini circuit breaker, QO, 15A, 1 pole, 120/240VAC, 10kA, plug in mount, AC shunt | Mayer Electric

Mayer Electric Supply . QO1151021

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerMayer Electric Supply
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 15A, 1 pole, 120/240VAC, 10kA, plug in mount, AC shunt | Mayer Electric
UPC785901493808
Weight0.295
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Mini-circuit-breaker-QO-15A-1-pole-120-240-VAC-10-kA-plug-in-mount-AC-shunt-trip-785901493808
jsonUrlData27acd7770-8cd8-4937-8f2e-abd20062ceaf
length_AttribDepth
moq, multiple, tierMinQty11
MPNQO1151021
qtyInStock0
SKUSQDQO1151021
tierPrice1113.14
width38.0
width_AttribWidth
Circuit Breaker ApplicationHACR and Switching Duty rated
Mounting Modeplug-in
Circuit Breaker Typestandard
Range Of ProductQO
Poles Description1P
Accessory / Separate Part Typeshunt trip 120/208/240 V AC
Electrical Connectionpressure plate
Line Rated Current15 A
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage120/240 V AC || 120 V AC || 48 V DC
Warranty18 months
Height76 mm
Breaking Capacity10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
Tightening Torque5-5 N.m 10-25 mm? (AWG 8...AWG 2)
Number Of Spaces Required2
Awg GaugeAWG 14...AWG 8 copper or aluminium
Width38 mm
Depth74 mm
Net Weight0.295 kg
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Halogen Content PerformanceHalogen free product
Product CertificationsUL Listed || CSA
Ambient Air Temperature For Operation40 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDQO1151021111 @ $113.14
