| Brand name, Manufacturer name, Manufacturer | Uniview |
|---|
| Condition | NEWCONDITION |
|---|
| DimensionUnit | m |
|---|
| Extra Product Name | Buy Uniview NVR301-04S3-P4, 1 SATA Series 4-Chanel Network Video Recorder - Prime Buy |
|---|
| Weight | 1.1 |
|---|
| WeightUnit | lbs |
|---|
| Weight_Attrib | Weight (without HDD) |
|---|
| moq, multiple, tierMinQty1 | 1 |
|---|
| MPN, SKU | NVR301-04S3-P4 |
|---|
| qtyInStock | 2 Weeks Factory Lead Time |
|---|
| tierPrice1 | 259.00 |
|---|
| width | 64.0 |
|---|
| width_Attrib | Incoming Bandwidth |
|---|
| IP Video Input, Synchronous Playback, UMD by Camera | 4-ch |
|---|
| Incoming Bandwidth | 64Mbps |
|---|
| Outgoing Bandwidth | 48Mbps |
|---|
| Remote Users | 128 |
|---|
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP, RTSP |
|---|
| Recording Resolution, Live view/Playback | 4K/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
|---|
| Audio Output | 1-ch, RCA |
|---|
| Audio Compression | G.711A, G.711U |
|---|
| Liveview display | 1/4 |
|---|
| Corridor Mode Screen | 3/4 |
|---|
| FTP/Schedule/Event Snapshot | 1-ch snapshot, up to D1 resolution |
|---|
| Decoding Format | Ultra 265/H.265/H.264 |
|---|
| Capability | 1 x 4K at 30, 4 x 5MP at 25, 4 x 4MP at 25, 4 x 3MP at 25, 4 x 1080p at 30 |
|---|
| SATA | 1 SATA interfaces |
|---|
| Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
|---|
| VCA Detection by Camera | Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Audio Detection, Ultra Motion Detection (UMD) |
|---|
| VCA Search | Behavior Search |
|---|
| Smart Intrusion Prevention (SIP) by Camera | 4-ch (Alarm only, no image) |
|---|
| General Alarm | Motion, Tampering, Human Body Detection, Video Loss, Alarm Input |
|---|
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
|---|
| Network Interface | 1 RJ-45 10M/100Mself-adaptive Ethernet Interface |
|---|
| USB Interface | Rear panel: 2 x USB2.0 |
|---|
| RS232, RS485, Alarm In, Alarm Out | NA |
|---|
| Interface | 4 RJ-45 10M/100Mself-adaptive Ethernet Interface |
|---|
| Max Power | Max 30W for single port, Max 54W in total |
|---|
| Supported Standard | IEEE 802.3at, IEEE 802.3af |
|---|
| Power Supply | 48V DC, Power Consumption: ≤9 W (without HDD) |
|---|
| Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
|---|
| Dimensions (WxDxH) | 260mm x240mm x 46 mm (10.2" x 9.4" x1.8") |
|---|
| Weight (without HDD) | ≤1.1kg (2.43lb) |
|---|
| Certification | CE, FCC, UL, RoHS, WEEE |
|---|
| CE | EN 55032: 2015, EN 61000-3-3: 2013, EN IEC 61000-3-2: 2019, EN 55035: 2017 |
|---|
| FCC | Part15 Subpart B, ANSI C63.4 |
|---|
