DSS Racing K3-4812-3700

DSS Racing . K3-4812-3700

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, BrandDSS Racing
DimensionUnitinch
Extra Product NameDSS Racing K3-4812-3700
UPC00194403199642
diameter, width0.866
height1.21
height_AttribCompression Height (in.)
length5.933
length_AttribRod Length
moq, multiple, tierMinQty11
MPN, Manufacturer's Part NumberK3-4812-3700
qtyInStockJun 28, 2023
SKU, Summit Racing Part NumberDMS-K3-4812-3700
tierPrice11189.9500
width_AttribPin Diameter (in.)
Part TypePistons
Piston Rings Included, Wrist Pin Retainers Included, Wrist Pin IncludedYes
Bore (in )3.700 in.
Bore (mm)93.980mm
Stroke3.543 in.
Engine Stroke TypeStock
Actual Engine Displacement5.0L/305
Rod Length5.933 in.
Piston StyleFlat top, with three valve reliefs
Piston MaterialForged aluminum
Compression Height (in )1.210 in.
Piston Head Volume (cc)+3.00cc
Wrist Pin StylePress-fit or floating
Pin Diameter (in )0.866 in.
Piston Ring Thickness1.50mm x 1.50mm x 3.00mm
File Fit, GaplessNo
Top Ring Thickness, Second Ring Thickness1.5mm
Top Ring MaterialSteel
Top Ring Facing MaterialGas nitrided
Second Ring Material, Second Ring Facing MaterialIron
Oil Ring Thickness3.0mm
Oil Ring MaterialStainless steel
Oil Ring TensionStandard
QuantitySold as a set of 8.
Special AttentionFits 2-valve applications with PI or Twisted Wedge cylinder heads only.

Distributor offers

SellerSKUMOQIn stockMultiplePrices
Summit RacingDMS-K3-4812-37001Jun 28, 202311 @ $1189.95
