Johnson Controls

THERMOSTAT REV RR HORIZ F

Johnson Controls . T-4003-203

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameJohnson Controls
DimensionUnitinch
GraingerSku42C117
UPCNone
UnitOfMeasureEA
Weight0.38
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
extendedLead40
extendedQty-2
height, length, moq, multiple, tierMinQty1, width, Number of Pipes1
jsonUrlData924526ffbdad25e5923b
MPNT-4003-203
qtyInStock0
qtyInStockOverrideDrop Ship
SKUG0948109
tierPrice1241.00
urlhttps://www.zoro.com/johnson-controls-thermostat-rev-rr-horiz-f-t-4003-203/i/G0948109/
Item, Product TypePneumatic Thermostat
Temperature SettingsSingle Temperature
Number of Pipes/Air Flow Output1 Pipe, High Volume
Air Consumption20 scim
Manual Indexing SwitchNo
Thermostat Action, ActionReverse
Air Connection Outside Diameter1/8 in
Mounting DirectionHorizontal
Maximum Control Temperature85 Degrees F
Temperature Control Range55 Degrees to 85 Degrees F
Pneumatic Thermostat Type/Indexing Switch, Pneumatic Thermostat TypeRemote Reset
Maximum Air Pressure25 psig
Temperature ScaleCelsius/Fahrenheit
Overall Width3 1/8 in
Differential TypeFixed
Air Flow OutputHigh Volume
Overall Height2 1/8 in
Mounting Direction/Includes CoverHorizontal, No
Fitting ConnectionBarbed 5/32 in
Sensor TypeBi-Metallic Spring
Control Air Pressure Settings13 psig (Day)/ 25 psig (Night)
Number of DialsSingle
Minimum Control Temperature55 Degrees F
Overall Depth1 3/4 in
Air Flow Capacity400 scim
Country of Origin (subject to change)Mexico

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG0948109111 @ $241.00
RadwellT-4003-203111 @ $250.00
SupplyHouseT-4003-20311
ZoroG7016844111 @ $278.57
Voomi SupplyT-4003-203111 @ $281.58
uri.comT40032031-211 @ $590.90
cappusa.com557912111 @ $201.50
midwestapplianceparts.comT-4003-203-JO-P1Current Unavailable - No ETA Available11 @ $287.44
furnacepartsource.comT-4003-203111 @ $309.74
energycontrol.comT-4003-2031Call for Lead Time11 @ $263.25
gsistore.comT-4003-203111 @ $257.69
waterpumpsnow.comT-4003-20311
GalcoT-4003-203-JHSN111 @ $306.43
industrialstores.comT-4003-2031Usually Ships 1-2 Weeks11 @ $310.23
Grainger42C117111 @ $274.00
blackhawksupply.comT-4003-2031-211 @ $260.00
alliedcontrols.comT-4003-2031Factory Stock11 @ $240.95
grainger.caJHCT4003203111 @ $198.67
