OA825AP-22-1WB Orion Fans | Fans, Thermal Management | DigiKey
OA825 Series 3000 RPM 80 x 80 x 25 mm 25 CFM 230 V Dual Ball Bearing AC Fan
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| Extra Product Name | OA825AP-22-1WB Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | OA825AP-22-1WB |
| qtyInStock | 149 |
| SKU | 1053-1099-ND |
| Part Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Square - 80mm L x 80mm H |
| Width | 27.00mm |
| Air Flow | 25.0 CFM (0.700m?/min) |
| Static Pressure | 0.210 in H2O (52.3 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features, Ingress Protection, Weight, Current Rating (Amps) | - |
| Noise | 25.0dB |
| Power (Watts) | 9.00W |
| RPM | 3000 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | -4 ~ 176?F (-20 ~ 80?C) |
| Approval Agency | cURus, TUV |
| Voltage Range | 160 ~ 260VAC |
| Material - Frame | Aluminum |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 60000 Hrs @ 40?C |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 1053-1099-ND | 1 | 149 | 1 | |
| Onlinecomponents.com | OA825AP-22-1WB | 1 | 1 | 1 @ $14.36, 2 @ $13.64, 26 @ $12.96, 101 @ $12.31, 501 @ $11.88, 1001 @ $11.28 | |
| Electroshield | OA825AP-22-1WB | 1 | 4 | 1 | |
| RS Delivers | 2508490710 | 1 | 1 | ||
| Bisco | OA825AP-22-1WB | 1 | 1 | ||
| Future Electronics | 5806823 | 20 | 20 | 20 @ $21.25, 5 @ $17.80, 10 @ $16.49, 25 @ $14.91, 50 @ $13.81 | |
| AmazonSC | B00JJ4I3UM | 1 | 1 | 1 @ $53.85 | |
 Newark | 89AH2476 | 1 | 34 | 1 | 1 @ $22.68, 5 @ $22.08, 10 @ $21.24, 25 @ $19.92, 50 @ $18.60, 100 @ $17.28 |
 Mouser | 670-OA825AP221WB | 1 | 63 | 1 | 1 @ $17.61, 10 @ $16.08, 100 @ $13.33, 1000 @ $13.02, 10000 @ $13.02 |
 we-supply.com | OA825AP-22-1WB | 1 | 4 | 1 | 1 @ $23.10 |
 Galco | OA825AP-22-1WB-ORIN | 1 | 1 | 1 @ $0.00 | |
| 10141425 | 1 | 1 | 1 @ $20.00 | ||
| us.rs-online.com | 70103314 | 1 | 37 | 1 | 1 @ $22.28, 10 @ $20.35, 25 @ $19.57, 50 @ $18.29, 100 @ $16.87, 250 @ $16.61 |
 Newark | 51AK1571 | 1 | 1 | 1 @ $25.39, 25 @ $23.27, 50 @ $21.61, 100 @ $20.90, 250 @ $20.20 |
