spire | 222AK00174B EATON Industrial Hydraulics | SunSource.com

222AK00174B EATON | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.

None . 222AK00174B

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Auxiliary mounting, Control special features, Pump special features, Sub brandNone
Extra Product Namespire | 222AK00174B EATON Industrial Hydraulics | SunSource.com
jsonUrlData1791b58b-e503-4b56-b911-ae28000a02b6
keywordsAEC028R09AAA1AA2425000002002000B0HB 222AK00174B
moq, multiple, tierMinQty11
MPN, SKU222AK00174B
qtyInStock, tierPrice10
snippet222AK00174B EATON | Search our online catalog of Industrial Hydraulics. Start your quote online to connect with our team of technical experts for support.
ApplicationConstruction, Agriculture, Truck and Bus, Material Handling, Other Mobile
Bearing life at rated pressure5850 hr
Code title220 Series Mobile Piston Pump
Continuous allowable case pressure19 psi
Controller typePressure Flow Compensator with .4375-20 SAE O-Ring Load Sense Port Left Side
Design code11Second
Diagnostic pressure ports.4375-20 UNF-2B SAE O-Ring Ports - Suction and Pressure - Plugged
Displacement28 cubic centimetre per revolution
Drain port size location.875-14 UNF-2B O-Ring Port - Top (28Cc and 45Cc)
EccnEAR99
Fluid cleanliness21/18/13
Front mounting2 Bolt B
Housing materialCast Iron
Icc2Mobile - OC Piston Pumps
IdentificationMark Eaton Product Number and Full Model Code On Label
Inlet pressure64 psi
Input shaft13 Tooth 16/32 Spline, Shaft Extension 41.1 [1.62]
Input speed at 0 8 bar absolute2700 revolutions per minute
Input speed at 1 0 bar absolute3000 revolutions per minute
Input speed maximum3600 revolutions per minute
Input speed minimum500 revolutions per minute
Main port size locationRear Ports; Suction - 1.625-12 UN-2B SAE O-Ring Port; Pressure - 1.0625-12 UN-2B SAE O-Ring Port
Maximum case pressure45 psi
Maximum displacement optionExternal Manual Stroke Adjustment (Set At Maximum)
Maximum input power39.2 kilowatt
Maximum input torque1106 inch pound (pound inch)
Maximum pressure compensator setting196.5 bar
Maximum recommended operating viscosity40 centistokes
Minimum pressure compensator setting189.6 bar
Minimum recommended operating viscosity16 centistokes
Model CodeAEC028R09AAA1AA2425000002002000B0HB
Nominal pressure rating4060 psi
PaintBlack
Peak pressure rating5000 psi
Product height9.02
Product height uom, Product length uom, Product width uominch
Product length9.68
Product trade nameX20
Product weight35.9
Product weight uompound
Product width6.85
Shaft rotationRight
Shaft sealsNitrile
Torque control setting0 inch pound (pound inch)
