Mini circuit breaker, QO, 25A, 2 pole, 120/240VAC, 10kA, bolt on mount, AC/DC shunt | Mayer Electric

SQUARE D . SQDQOB2251042

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 25A, 2 pole, 120/240VAC, 10kA, bolt on mount, AC/DC shunt | Mayer Electric
UPC, MPN, SKUSQDQOB2251042
Weight0.422
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Mini-circuit-breaker-QO-25A-2-pole-120-240VAC-10kA-bolt-on-mount-AC-DC-shunt-SQDQOB2251042
jsonUrlData2f3c4256e-816e-4a69-8eab-aeea00576a38
length_AttribDepth
moq, multiple, tierMinQty11
qtyInStock0
tierPrice10.0
width57.0
width_AttribWidth
Circuit Breaker Typestandard
Range Of ProductQO
Accessory / Separate Part Typeshunt trip 12/24 V AC/DC
Product Or Component Typeminiature circuit-breaker
Circuit Breaker ApplicationHACR rated
Mounting Modebolt-on
Poles Description2P
Electrical Connectionpressure plate
Line Rated Current25 A
[Ue] Rated Operational Voltage120/240 V AC || 120 V AC || 48 V DC
Warranty18 months
Height76 mm
Tightening Torque5-5 N.m 10-25 mm? (AWG 8...AWG 2)
Number Of Spaces Required3
Net Weight0.422 kg
Breaking Capacity10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
Awg GaugeAWG 14...AWG 8 copper or aluminium
Width57 mm
Depth74 mm
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
California Proposition 65 : WARNING: This product can expose you to chemicals includingLead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Eu Rohs DirectiveCompliant
Product CertificationsUL Listed || CSA
Ambient Air Temperature For Operation40 ?C
