OA938AP-22-1WB Orion Fans | Fans, Thermal Management | DigiKey
AC Fan Axial Ball Bearing 230V 160V to 260V 50CFM 32dB 92 X 92 X 38.5mm High Speed
Gallery
Attributes
| Brand name, Manufacturer name, Manufacturer, Mfr | Orion Fans |
|---|---|
| Extra Product Name | OA938AP-22-1WB Orion Fans | Fans, Thermal Management | DigiKey |
| atoms, minimum, moq, multiple | 1 |
| MPN | OA938AP-22-1WB |
| qtyInStock | 63 |
| SKU | 1053-1115-ND |
| Part Status | Active |
| Voltage - Rated | 230VAC |
| Size / Dimension | Square - 92mm L x 92mm H |
| Width | 38.50mm |
| Air Flow | 50.0 CFM (1.40m?/min) |
| Static Pressure | 0.220 in H2O (54.8 Pa) |
| Bearing Type | Ball |
| Fan Type | Tubeaxial |
| Features, Ingress Protection, Weight, Current Rating (Amps) | - |
| Noise | 32.0dB |
| Power (Watts) | 9.00W |
| RPM | 3100 RPM |
| Termination | 2 Wire Leads |
| Operating Temperature | -4 ~ 176?F (-20 ~ 80?C) |
| Approval Agency | cURus, TUV |
| Voltage Range | 160 ~ 260VAC |
| Material - Frame | Aluminum |
| Material - Blade | Polybutylene Terephthalate (PBT) |
| Lifetime @ Temp | 60000 Hrs @ 40?C |
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 1053-1115-ND | 1 | 63 | 1 | |
| OA938AP-22-1WB | 1 | 4 | 1 | 1 @ $14.36, 25 @ $13.64, 100 @ $12.96, 500 @ $12.31, 1000 @ $11.88, 2000 @ $11.28 | |
| Electroshield | OA938AP-22-1WB | 1 | 1 | 1 | |
 Carlton Bates Company | 40308486159 | 1 | 1 | 1 @ $0.00 | |
| RS Delivers | 2508491038 | 1 | 1 | ||
| Future Electronics | 5841929 | 20 | 20 | 20 @ $20.87, 5 @ $17.48, 10 @ $16.20, 25 @ $14.64, 50 @ $13.57 | |
 Newark | 89AH2490 | 1 | 1 | 1 @ $24.39, 5 @ $23.74, 10 @ $22.84, 25 @ $21.42, 50 @ $20.00, 100 @ $18.58 | |
| AmazonSC | B005T8Q69C | 1 | 1 | 1 @ $22.22 | |
 Arrow | OA938AP-22-1WB | 1 | 33 | 1 | 1 @ $16.99, 10 @ $15.31, 100 @ $13.03, 1000 @ $12.68, 10000 @ $12.68 |
| Mouser | 670-OA938AP221WB | 1 | 34 | 1 | 1 @ $17.61, 10 @ $16.08, 100 @ $13.33, 1000 @ $13.02, 10000 @ $13.02 |
| Hutch and Son | OA938AP-22-1WB | 1 | 1 | ||
 Galco | OA938AP-22-1WB-ORIN | 1 | 1 | 1 @ $25.29 | |
| 10141469 | 1 | 1 | 1 @ $21.50 | ||
| us.rs-online.com | 70103412 | 1 | 10 | 1 | 1 @ $25.56, 10 @ $23.34, 25 @ $22.46, 50 @ $20.98, 100 @ $19.35, 250 @ $19.06 |
 Newark | 83AK2418 | 1 | 3 | 1 | 1 @ $27.52, 25 @ $25.22, 50 @ $23.42, 100 @ $22.66, 250 @ $21.89 |
