Mini circuit breaker, QO, 25A, 2 pole, 240VAC, 22kA, bolt on mount, AC shunt | Mayer Electric

SQUARE D . SQDQOB225VH1021

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerSQUARE D
DimensionUnitmm
Extra Product NameMini circuit breaker, QO, 25A, 2 pole, 240VAC, 22kA, bolt on mount, AC shunt | Mayer Electric
UPC3606486144749
Weight0.485
WeightUnitkg
Weight_AttribNet Weight
depth, length74.0
height76.0
height_AttribHeight
jsonUrlData/Product/SQUARE-D-Mini-circuit-breaker-QO-25A-2-pole-240VAC-22kA-bolt-on-mount-AC-shunt-SQDQOB225VH1021
jsonUrlData2663f79b8-b810-4798-adf5-aeea00576a48
length_AttribDepth
moq, multiple, tierMinQty11
MPN, SKUSQDQOB225VH1021
qtyInStock0
tierPrice1317.71
width57.0
width_AttribWidth
Circuit Breaker ApplicationHACR rated
Mounting Modebolt-on
Circuit Breaker Typestandard
Range Of ProductQO
Poles Description2P
Accessory / Separate Part Typeshunt trip 120/208/240 V AC
Electrical Connectionpressure plate
Line Rated Current25 A
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage120/240 V AC || 240 V AC || 120 V AC
Warranty18 months
Height76 mm
Breaking Capacity22 kA 120/240 V AC 50/60 Hz || 22 kA 240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
Tightening Torque4.6-4.6 N.m
Number Of Spaces Required3
Awg GaugeAWG 14...AWG 8 copper or aluminium
Width57 mm
Depth74 mm
Net Weight0.485 kg
China Rohs RegulationProduct out of China RoHS scope. Substance declaration for your information.
Rohs Exemption Information, Mercury Free, Toxic Heavy Metal FreeYes
Sustainable Offer StatusGreen Premium product
Eu Rohs DirectiveCompliant
Reach RegulationReference contains Substances of Very High Concern above the threshold
Halogen Content PerformanceHalogen free product
Product CertificationsUL Listed || CSA
Ambient Air Temperature For Operation40 ?C

Distributor offers

SellerSKUMOQIn stockMultiplePrices
mayerelectric.comSQDQOB225VH1021111 @ $317.71
