2500 Watt, 12V Inverter / 120 Amp PFC Charger, Modified Sine Wave

ME Series 2500 Watt Inverter/Charger The ME2512 model is Magnum's Modified Sine Wave Inverter, 12V with 2500 Watts of Power plus a Power Factor Corrected (PFC) 120 amp Charger. Popular for use in marine and RV applications. This Magnum unit uses less energy from a generator than a standard charger - using only 15 amps per 100 amps versus 23 amps used by standard chargers. Weight: 42 lbs. ETL listed to the stringent requirements of UL/CUL 458 and CSA C22.2 #107.1-01 ensuring this is a safe, reliable power inverter. Easy-to-install: Install the ME Series in four easy steps. Connect the inverter's output to your distribution circuits or electrical panel, connect your shore power cable (AC) to the inverter's easy-to-reach terminal block, connect the batteries, and switch on the power. Magnum Series ME Features: Versatile mounting: Mount the ME Series on a shelf, bulkhead, or even upside down. Lightweight: The lightweight aluminum base and cover also provides noise reduction and corrosion resistance. Multiple ports: includes an RS485 communication port for network expansion, and a remote port. Accessible design: The extra large AC access cover with terminal screw block and 360 degrees DC connection terminals with covers make this inverter more accessible when it needs to be. Convenient switches: The ME Series comes with an on/ off inverter-mounted switch with an easy-to-read LED indicator. Expanded transfer relay: 60 Amp transfer service is available on all models. Three-year (36-month) limited warranty. Accessories and Options Available (Not included) Remote control: For convenient finger-tip operation, including the new one-knob(TM) programming. AGS module: Automatically starts and stops your generator based on temperature or battery voltage. The ME Series Inverter/Charger For Mobile Applications is Powerful, Easily Used and Cost Effective.

Magnum 2500W 12V Inverter/120Amp PFC Charger ME-2512 Introducing the ME Series Inverter/Charger from Magnum Energy -- A new generation inverter designed specifically for rugged recreational vehicle use. The ME Series is powerful, easy-to-use, and best of all, cost effective. The ME series is ETL Listed to the stringent requirements of UL/cUL 458, ensuring that the inverter is safe and reliable. Install the ME series in four easy steps: simply connect the inverter's output to your distribution circuits or electrical panel, connect your shore power cable (AC) to the inverter's easy-to-reach terminal block, connect the batteries, and switch on the power . Magnum model Continuous watts Battery voltage AC out volts/hertz No load draw Charger amps Peak AC surge Weight (lbs) Item code MM612-AE 600 12VDC 120V/60Hz 10W 30 10A 14 030-02302 MM1212-AE 1200 12VDC 120V/60Hz 16W 70 20A 20 030-02304 ME2012 2000 12VDC 120V/60Hz 11W 100 37A 38 030-02305 ME2512 2500 12VDC 120V/60Hz 12W 130 45A 42 030-02311 ME3112 3100 12VDC 120V/60Hz 12W 150 50A 45 030-02315

The ME2512 12VDC inverter/charger by Magnum Energy is designed specifically for RV use. The power-factor-corrected battery charger efficiently charges your batteries even at low AC voltage from low-cost generators, while the modified sine wave inverter keeps the cost down. Additionally, the battery temperature sensor works with the charger for optimum battery charging. It comes in three power levels. ME2512 is ETL Listed to UL/cUL 458 for RV, marine and mobile use. 3-year warranty. Dimensions: 16.6 x 8.4 x 4.7 inches. Features: Power Factor Corrected (PFC) Charger: The PFC charger is built into all of the ME inverter chargers. It uses less energy from a generator than a standard charger – using only 15 amps per 100 amps versus 23 amps used by standard chargers Versatile mounting: Mount the ME Series on a shelf, bulkhead, or even upside down. Lightweight: The lightweight aluminum base and cover also provides noise reduction and corrosion resistance. Multiple ports: The ME Series provides multiple ports, including an RS485 communication port for network expansion, and a remote port. Accessible design: The extra large AC access cover with terminal screw block and 360° DC connection terminals with covers make this inverter more accessible when it needs to be. Convenient switches: The ME Series comes with an on/ off inverter-mounted switch with an easy-to-read LED indicator. Expanded transfer relay: 60 Amp transfer service is available on all models. Magnum Energy ME Specifications:

Magnum Energy ME Inverter/Charger Performance Features ME Series is powerful, easy-to-use, and best of all, cost effective Modified Sine Wave 2500 Watts Continuous Power 5000 Watts Surge Capacity 12VDC Input 120 Amp Five Stage DC Charger Ideal for RV or Marine Applications Optional Remote Control Protection Features Overcurrent Protection Overtemperature Protection Three Year Warranty MFG# ME2512

The ME Series Inverter / Charger from Magnum Energy is a modified sine wave inverter designed specifically for rugged mobile applications. The ME Series is powerful, easy-to-use, and best of all, cost effective. Safe and reliable: The ME Series is ETL Listed to the stringent requirements of UL/cUL 458 and CSA C22.2 #107.1-01, ensuring that the inverter is safe and reliable. Easy-to-install: Install the ME Series in four easy steps: simply connect the inverters output to your distribution circuits or electrical panel, connect your shore power cable (AC) to the inverters easy-to-reach terminal block, connect the batteries, and switch on the power. Features Power factor corrected charger Three power models available Versatile mounting Lightweight Multiple ports Accessible design Convenient switches Expanded transfer relay Backed by a three-year (36-month) limited warranty Product Manual | Download Product Specifications | Download Available For Marine Systems RV Systems

The ME Series Inverter / Charger from Magnum Energy is a modified sine wave inverter designed specifically for rugged mobile applications. The ME Series is powerful, easy-to-use, and best of all, cost effective
