F715-50-B5-G 50:1 Ratio Gearbox | Boston Gear?

Speed Reducer: 35 Nominal Output RPM, 56C, 50:1, 0.25 hp Max. Input HP This listing is for each. Technical Specification Item Speed Reducer Speed Reducer Type C-Face Shaft Orientation Right Angle Duty Standard Input RPM 1, 750 Nominal Output RPM 35 Worm Center Distance 1.54 in Bore Dia. 5/8 in Frame 56C Overhung Load 300 lb Nominal Ratio 50:1 Max. Input HP 0.25 hp Max. Output Torque 315.0 in-lb Output Torque @ 1/4 HP 210 in-lb Output Torque @ 1/3 HP 315 in-lb Number of Stages 1 Rotation Forward/Reversible Base Optional Mounting Any Position Lubrication Klubersynth UH1 6-460 Seal Type Double Lip Bearings Tapered Roller Pinion Material Hardened Steel Gear Type Worm Gear Material Hardened and Ground Steel Worm Gear Material Bronze Housing Material Cast Iron Finish Powdered Epoxy Paint Single/Double Output/Universal Single Output Solid/Hollow Output Shaft Solid Output Shaft Dia. 3/4 in Output Shaft Height 1 29/32 in Standards AGMA WARNING Cancer and Reproductive Harm -

WORM SPEED REDUCER

Standard Cast Iron C-Face Speed Reducer, Single Output, 300 lb. Overhung Load<p><b>Features:</b><li>Nominal Output RPM-350</li><li>Worm Center Distance-1.54</li><li>Bore Dia.-5/8</li><li>Frame-56C</li><li>Overhung Load-300 lb.</li><li>Nominal Ratio-5:1</li><li>Max. Input HP-1</li><li>Max. Output Torque-164.00 in.-lb.</li><li>Output Torque @ 1 HP-123 in.-lb.</li><li>Output Torque @ 1.5 HP-164 in.-lb.</li>
