Grundfos 98126855 MAGNA1 80-100 F CAST IRON 230V - MROSupply.com

Grundfos . 98126855

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerGrundfos
CategoryL1Pumps
CategoryL2Centrifugal Pumps
CategoryL3Circulating Pumps
DimensionUnitmm
Extra Product NameGrundfos 98126855 MAGNA1 80-100 F CAST IRON 230V - MROSupply.com
length360.0
length_AttribPort-to-port length
moq, multiple, tierMinQty11
MPN, Product no98126855
qtyInStock0
SKU5027039
snippetThe 98126855 is produced by Grundfos and is described as a Grundfos 98126855 MAGNA1 80-100 F CAST IRON 230V
tierPrice13594.14
Rated voltage1 x 208-230 V
Pipe connectionGF80
Density (lb/ftBi)61.35
Temperature range (F)14 - 230
Power input - P131 .. 1014 W
TF class110
Density983.2 kg/m?
Range of ambient temperature (?C)0 - 40
Mains frequency60 Hz
Pumped liquidWater
Product nameMAGNA1 80-100 F
Pump housingCast iron
Maximum current consumption0.31 .. 4.45 A
Energy (EEI)0.19
Head max100 dm
Selected liquid temperature (?C)60
ApprovalscETLus, Proposition 65
Insulation class (IEC 85)F
Flange standardGF
Maximum operating pressure (bar)12
Pressure ratingPN12
Port-to-port length360 mm
ModelB
Liquid temperature range (?C)-10 - 110
ImpellerPES 30%GF
Enclosure class (IEC 34-5)X4D

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MRO Supply5027039111 @ $3594.14
PlumbersStock42217411
Edge Supply981268551-211 @ $5108.00
pumpproducts.com981268551(Usually Ships 7-10 Days)11 @ $4034.00
