PLEXUS . 68505

This is a kit that includes on cartridge, one mixing nozzle one reusable mixing sheet, and one small hand plunger for light-duty dispensing. Plexus MA685 (68505) is a two-part 10:1 mix ratio Clear MMA Acrylic adhesive designed for structural bonding of thermoplastic, metal, and composite assemblies. Combined at a 10:1 ratio, MA685 has a working time of about 10 minutes. This product offers a combination of high strength and toughness (vibration & shock-resiatance) as well as the ability to bond a wide range of materials. Characteristics Room Temperature Cure Working Time 8-12 minutes Fixture Time 18 – 25 minutes Operating Temperature -67°F – 250°F (-55°C – 121°C) Gap Filling 0.03 in. – 0.125 in. (0.75 mm – 3.2 mm) Mixed Density 8.10 lbs/gal (0.97 g/cc) Chemical Excellent resistance to: Water, UV Light (non-yellowing) Scuffing/scratching, impacts, High Temperatures Please Note: These cartridges are designed to work best with a 50ml cartridge Dispenser. We strongly advise you use a 50ml Dispenser for this, and all 50ml cartridges. However, If you do not have or want this type of gun, then this package may be right for you. It includes a manual hand plunger that can be used to dispense the epoxy, and two extrustion options 1) a mixing nozzle and 2) a reusable mixing sheet. The two parts may prove a little hard to push out, if so then simply take the mixing nozzle off and exturde the two parts onto the mixing sheet and manually mix with a stick or the mixing nozzle manually. Also, If interested, please click on the kit configuration above that includes a Dispenser… or check out the “MixPac 50ml Dispenser”

Plexus MA685 (68505) is a two-part 10:1 mix ratio Clear MMA Acrylic adhesive designed for structural bonding of thermoplastic, metal, and composite assemblies. Combined at a 10:1 ratio, MA685 has a working time of about 10 minutes. This product offers a combination of high strength and toughness (vibration & shock-resiatance) as well as the ability to bond a wide range of materials. Characteristics Room Temperature Cure Working Time 8-12 minutes Fixture Time 18 – 25 minutes Operating Temperature -67°F – 250°F (-55°C – 121°C) Gap Filling 0.03 in. – 0.125 in. (0.75 mm – 3.2 mm) Mixed Density 8.10 lbs/gal (0.97 g/cc) Chemical Excellent resistance to: Water, UV Light (non-yellowing) Scuffing/scratching, impacts, High Temperatures

This is a kit that includes on cartridge, one syringe, and one MixPac DMA50 Dispenser with the included 10:1 ratio plunger... MixPac is the industry-standard for efficient adhesive dispensing. Plexus MA685 (68505) is a two-part 10:1 mix ratio Clear MMA Acrylic adhesive designed for structural bonding of thermoplastic, metal, and composite assemblies. Combined at a 10:1 ratio, MA685 has a working time of about 10 minutes. This product offers a combination of high strength and toughness (vibration & shock-resiatance) as well as the ability to bond a wide range of materials. Characteristics Room Temperature Cure Working Time 8-12 minutes Fixture Time 18 – 25 minutes Operating Temperature -67°F – 250°F (-55°C – 121°C) Gap Filling 0.03 in. – 0.125 in. (0.75 mm – 3.2 mm) Mixed Density 8.10 lbs/gal (0.97 g/cc) Chemical Excellent resistance to: Water, UV Light (non-yellowing) Scuffing/scratching, impacts, High Temperatures
