Corbin Russwin UT5255 ESE 626 RHR CL6 UT5255 Classroom Lockset RHR x IC, Satin Chrome

Assa Abloy . UT5255 ESE 626 RHR CL6

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Manufacturer ParentAssa Abloy
CategoryIdL3Mechanical Locksets
CategoryL1Windows and Door Hardware
CategoryL2Commercial and Residential Door Hardware
DimensionUnitinch
Extra Product NameCorbin Russwin UT5255 ESE 626 RHR CL6 UT5255 Classroom Lockset RHR x IC, Satin Chrome
atoms, moq, multiple, tierMinQty1, Package Qty1
color, ColorBright Chrome
height4.875
height_AttribStrike Height
length9.5
length_AttribPackage Length
MPNUT5255 ESE 626 RHR CL6
qtyInStock-2
qtySourceFieldMap
tierPrice11917.4
width8.0
width_AttribPackage Width
Package Length9.5"
Lever/Knob DesignES - Lever
Strike Height4-7/8 In.
Base MaterialBrass or Bronze
Rose/Escutcheon DesignE - Rose
Strike TypeASA
Color Code626/US26D
Bolt Protection3/4 In.
Package Width8"
ScrewsCombination
Package Height3.375"
Cylinder TypeLFIC Less Core-Large Format Prep
Latch Backset Dim2-3/4 In.
Strike Width1-1/4 In.
Dust BoxNone
Special MarksFull size/large format interchangeable core, Fire rated 3 Hours {A}, Complies with ADA accessibility guidelines
Fire Rated3 Hours {A}
Hand, HandingRight Hand Reverse
Burglar RatedNo
Latch TypeDeadlocking
Function55-Classroom
Package Volume256.5
Thickness1-3/4 In.
Finish, Finish Description, Finish FamilySatin Chrome
GradeANSI/BHMA Grade 1
Backset2-3/4 Inch
Lever StyleESE-Essex
Rose/Escutcheon TrimSquare
Product TypeCylindrical Lock
StrikeANSI, 1-1/4 Inch x 4-7/8 Inch, 1-1/4 Inch Lip, Square Corner
Projection2.4375
Lever Length5.3125
Door Thickness1-3/4 inch
Bore Size2.1250
Strike NumberT-Strike, 1-1/8 Inch x 2-3/4 Inch, 1-1/4 Inch Lip, Sq Corner.
ADA ApprovedFalse
ApplicationSchools and Universities; Office Buildings; Hospitals; Municipal Buildings; Historic Buildings
Warranty1 Year
Handle TypeLever
Rose Diameter3-1/8" x 4-1/8"
Latch Throw3/4 Inch
ANSI FunctionF42
Door Cross Bore2.125 Inch
StandardsANSI/BHMA A156.2; Meets A117.1 Accessibility Code; UL/cUL Listed
Cylinder Type UsedLarge Format Interchangeable Core With Less Core
Function FamilyClassroom
Product Projection2-7/16 Inch
Trim MaterialForged (Lever; Escutcheon)
FeaturesFactory Pre-Assembled for Quick, Economical, One-Piece Installation, No Job Site Assembly Required; 3/4" Radius Latchbolt; Designed to Wedge more Tightly into the Strike
ADA CompliantYES
Cylinder MaterialBrass
Lever Length-Inches5.3125 Inch
Knob/Lever Size5-5/16 Inch
Latch Bolt MaterialChrome Plated Brass
Lever Style FamilyStraight Return Lever
Sub-SeriesUT5255-ESE-626-RHR-CL6

Distributor offers

SellerSKUMOQIn stockMultiplePrices
DK HardwareUT5255 ESE 626 RHR CL61-211 @ $1917.40
