Norton PR7500 690 7500 Series Surface Door Closer, Dark Bronze Painted

Assa Abloy . PR7500 690

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Manufacturer ParentAssa Abloy
CategoryIdL3Door Closer
CategoryL1Windows and Door Hardware
CategoryL2Door Closers and Accessories
DimensionUnitinch
Extra Product NameNorton PR7500 690 7500 Series Surface Door Closer, Dark Bronze Painted
atoms, moq, multiple, tierMinQty1, Package Qty1
color, Color, Finish DescriptionDark Bronze Painted
height7.75
height_AttribCase Height
length15.75
length_AttribCase Length
MPNPR7500 690
qtyInStock-2
qtySourceFieldMap
tierPrice1453.39
width12.75
width_AttribCase Width
Back CheckAdjustable
Package Volume333.59375
Case Width12.75"
Hand, HandingNon-Handed
GradeANSI/BHMA Grade 1
Fire Rated3 Hours {A}
Special MarksFire rated 3 Hours {A}
CoverPlastic
TypeSurface
ApplicationClassrooms; Offices; Main Entrance Doors; Hospitals; High Use High Abuse Doors
Case Length15.75"
Package Height3.5"
Case Height7.75"
Mounting LocationPush Side
Package Width6.25"
Case Volume1556.296875
Color Code690/US20
OriginUSA
BAA Qualified, Cold Weather FluidYes
Mounting StyleParallel Arm
Base MaterialVARIES
Package Length15.25"
Arm TypeParallel Arm Rigid
Closer SizeAdj. 1 to 6
Product TypeDoor Closer/Holder/Stop
Warranty30 Year Limited Warranty
Spring Size1-6
FunctionParallel Rigid Arm Non-Hold Open
Door Thickness1-3/4 inch
Door Size30" to 48" (Interior); 32" to 48" (Exterior)
Maximum Door Opening, Maximum Hold-Open180?
Product Height3-7/8 Inch
Product Length13-5/8 Inch
Product Width2-1/8 Inch
ADA CompliantYES
Finish FamilyDark Bronze
Product MaterialCast Aluminum
Closer CoverPlastic Cover
StandardsGrade 1 - ANSI/BHMA A156.4
Closer Arm TypeParallel Rigid Arm
Closer Fluid Temperature RangeExtremely High to as Low as -40?F
Closer FluidNorGlide
Closer Piston Diameter1-1/2 Inch
Closer Pinion Diameter5/8 Inch
Function FamilyNon Hold Open Door Closer
Mounting Hole Size2-3/8" x 6-3/4"
TemplatingFull Size
FeaturesBackcheck Positioning Valve; All Standard Arm Applications Allow Doors To Swing 180?
Minimum Hold-Open85?
Closer Hold-Openfalse
Sub-SeriesDC_Surface Mounted Closers_norton_18
Mounting TypePush or Pull Side

Distributor offers

SellerSKUMOQIn stockMultiplePrices
DK HardwarePR7500 6901-211 @ $453.39
