Maxim

Maxim . 288431

Gallery

Attributes

Brand name, Manufacturer name, Extra Product Name, BrandMaxim
ManufacturerMaxim Bailey Hydraulics
DimensionUnitinch
GraingerSku, MPN, Mpns, PartNumber, Part_number, StrippedMpns288431
UPC615986019382
UnitOfMeasureEA
Weight26.9 31.0
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabel, AdultProduct, Autographed, Memorabilia, TradeInEligibleFalse
countryOfOriginCN
extendedLead26
extendedQty, qtyInStockOverride-2
height, length, moq, multiple, tierMinQty1, width, Item_package_quantity, Number_of_items, PackageQuantity1
jsonUrlData924526ffbdad25e5923b
qtyInStock0
SKUG4735162
tierPrice1307.49
urlhttps://www.zoro.com/maxim-wc-welded-hydraulic-cylinder-3-bore-x-12-stroke-15-rod-288431/i/G4735162/
ItemHydraulic Cylinder
Bore Dia3 in
Stroke Length12 in
Max Pressure, Max Pressure PSI3000
Retracted Length, Retracted22.25 in
Rod Dia1.5 in
Port SizeSAE 8
Column Load21200 lbs
Extended Length, Extended34.25 in
Pin Diameter1 in
Country of Origin (subject to change)China
AsinB00MBP6XHQ
Bullet_point1.5 Rod Dia. 3 Bore x 12 Stroke 3 Bore, 12 Stroke, 1.5 Rod Dia., 22.25 Retract, 34.25 Extend, 21200 Load, SAE 8 Ports, 1 Pin Bailey Part Number: 288431
ClassificationId256361011
CurrencyUSD
DisplayNameLifting Cylinders
Height144 22 296 44 888
Identifier0615986019382 615986019382
IdentifierTypeEAN UPC
ItemClassificationBASE_PRODUCT
ItemName, Item_nameMaxim WC Welded Cylinder: 3 Bore x 12 Stroke, 3000 PSI, 1.5" Rod Diameter with SAE #8 Port Size, Retracted: 22.25 and Extended Length: 34.25, 1" Pin Dia., 288431
Item_type_keywordhydraulic-lifting-cylinders
Item_weight31.0
Keyword21200
Linkhttps://m.media-amazon.com/images/I/31k6dZ-RmNL._SL75_.jpg https://m.media-amazon.com/images/I/31k6dZ-RmNL.jpg https://m.media-amazon.com/images/I/41+mlzBPu5L._SL75_.jpg https://m.media-amazon.com/images/I/41+mlzBPu5L.jpg https://m.media-amazon.com/images/I/71-RRa7IKUL.jpg https://www.amazon.com/gp/bestsellers/industrial https://www.amazon.com/gp/bestsellers/industrial/256361011
List_price186.25
Materialsteel
ProductTypeOUTDOOR_LIVING
Product_description<p> The Maximª WC 3000 PSI welded cylinder is clevis mounted, and exceeds the highest standards. These Cylinders are designed for demanding applications and are built to ensure Maximum reliability and performance. Painted black. </p> <p> Intended Use: Double-acting applications ¥ Piston: Ductile iron ASTM A536 65-45-12 for excellent life ¥ Piston Lock Nut : Grade 8, high tensile zinc-plated ¥ Gland: Ductile iron ASTM A536 65-45-12 ¥ Tube: High tensile cold drawn tube, precision honed for extended seal life ¥ Tube seal: Nitrile O-ring with Polytemp hytrel back-up ¥ Rod: High tensile ground & polished hard chrome plated rod ¥ Rod seal: Std PolyPak with B lip design (Polyurethane U-cup with Nitrile O-ring expander) ¥ Wiper: Polyurethane ¥ End Mounts: Cast female clevises with pins and clips included ¥ Pin and Pin clip: High tensile zinc-plated steel ¥ Piston ID Seal: O-ring ¥ Piston OD seal: Hallite 755 piston seal ¥ Ports: SAE O-rings </p> <p>3 Bore, 12 Stroke, 1.5 Rod Dia., 22.25 Retracted, 34.25 Extended, 21200 Column Load, SAE 8 Port Size, 1 Pin Dia.</p>
Rank606 834791
TitleHydraulic Lifting Cylinders Industrial & Scientific
Typeean upc
Unitpounds
VariantMAIN PT01
WebsiteDisplayGroupbiss_display_on_website lawn_and_garden_display_on_website
WebsiteDisplayGroupNameLawn & Patio
Width1500 500 75

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG4735162111 @ $307.49
simsupply.comZO-G473516219711 @ $351.55

Related on Amazon

As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.

Maxim WC Welded Cylinder: 3 Bore x 12 Stroke, 3000 PSI, 1.5" Rod Diameter with SAE #8 Port Size, Retracted: 22.25 and Extended Length: 34.25, 1" Pin Dia., 288431
Brand: Maxim
<p> The Maximª WC 3000 PSI welded cylinder is clevis mounted, and exceeds the highest standards. These Cylinders are designed for demanding applications and are built to ensure Maximum reliability and performance. Painted black. </p> <p> Intended Use: Double-acting applications ¥ Piston: Ductile iron ASTM A536 65-45-12 for excellent life ¥ Piston Lock Nut : Grade 8, high tensile zinc-plated ¥ Gland: Ductile iron ASTM A536 65-45-12 ¥ Tube: High tensile cold drawn tube, precision honed for extended seal life ¥ Tube seal: Nitrile O-ring with Polytemp hytrel back-up ¥ Rod: High tensile ground & polished hard chrome plated rod ¥ Rod seal: Std PolyPak with B lip design (Polyurethane U-cup with Nitrile O-ring expander) ¥ Wiper: Polyurethane ¥ End Mounts: Cast female clevises with pins and clips included ¥ Pin and Pin clip: High tensile zinc-plated steel ¥ Piston ID Seal: O-ring ¥ Piston OD seal: Hallite 755 piston seal ¥ Ports: SAE O-rings </p> <p>3 Bore, 12 Stroke, 1.5 Rod Dia., 22.25 Retracted, 34.25 Extended, 21200 Column Load, SAE 8 Port Size, 1 Pin Dia.</p>
Details
  • 3 Bore, 12 Stroke, 1.5 Rod Dia., 22.25 Retract, 34.25 Extend, 21200 Load, SAE 8 Ports, 1 Pin
  • 3 Bore x 12 Stroke
  • 1.5 Rod Dia.
  • Bailey Part Number: 288431
