Hyd Cylinder,3 In Bore,14 In Stroke

Maxim . 288-338

Gallery

Attributes

Brand name, Manufacturer name, BrandMaxim
ManufacturerMaxim Bailey Hydraulics MAXIM
CategoryId10610
DimensionUnitinch
GraingerSku6FWX4
Extra Product NameHyd Cylinder,3 In Bore,14 In Stroke
UPCNone
UnitOfMeasureEA
Weight28.79 33.0
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabel, AdultProduct, Autographed, Memorabilia, TradeInEligibleFalse
countryOfOriginCN
height5
jsonUrlData924526ffbdad25e5923b
length25.2
moq, multiple, tierMinQty1, Case, Item_package_quantity, Number_of_items, PackageQuantity1
MPN, Part Number, ModelNumber, Model_number288-338
qtyInStock6
qtyInStockOverride-2
SKUG2666797
tierPrice1251.99
urlhttps://www.zoro.com/maxim-hyd-cylinder-3-in-bore-14-in-stroke-288-338/i/G2666797/
width5.1
Product Group, ProductGroup, ProductTypeBISS
Bore Dia3 in
Stroke Length14 in
Retracted Length22 in
Rod Dia1 1/2 in
Port Size#4 SAE
Extended Length36 in
Dimension D (In )2.126
Dimension E (In )0.750
Dimension B (In )3.740
Dimension C (In )2.251
Rod Dia (In )1-1/2
Port Size (SAE)#8
Bore Dia (In )3
Dimension A (In )0.188
Pin Dia1 in
ItemWelded Hydraulic Cylinder
Max Pressure3,000 psi
Column Load21,200 lb
Temp Range-20 Degrees to 220 Degrees F
Piston MaterialDuctile Iron
Rod Seal TypePolypak
TubesPrecision Honed Steel
Stroke (In )14
Inlet SAE (In )8
AsinB06XCQKKFX
Bullet_point1.5 Rod Dia. 3 Bore x 14 Stroke 3 Bore, 14 Stroke, 1.5 Rod Dia., 22 Retract, 36 Extend, 21200 Load, SAE 8 Ports, 1 Pin Bailey Part Number: 288338
CatIndustrial & Scientific
CatId16310091
CatTree16310091 16310161
CatalogNumberListZO G2666797
ClassificationId468240
ColorBlack
CurrencyUSD
DisplayNameCategories
FeaturePrice For: Each Tie Rods: High Tensile Rod Seal: Polypak Finish: Black Piston Material: Ductile Iron Tubes: Precision Honed Steel Bore Dia. (In.): 3 Piston Rod: High Tensile Strength Item: Hydraulic Cylinder Temp. Range: -20 to 220 Type: Double Acting Welded Style Stroke (In.): 14 Rod Dia. (In.): 1-1/2 Port Size (SAE): # 8 Dimension E (In.): 0.750
Height1070 139 21 278 396 42
Identifier0615986020098 615986020098
IdentifierTypeEAN UPC
ItemClassificationBASE_PRODUCT
ItemName, Item_name, OldTitleHyd Cylinder, 3 In Bore, 14 In Stroke
Item_type_keywordhydraulic-cylinders
Item_weight33.0
Keyword0009143503
Label, Man, Publisher, StudioMAXIM
Linkhttps://m.media-amazon.com/images/I/31-WQXUP7iL._SL75_.jpg https://m.media-amazon.com/images/I/31-WQXUP7iL.jpg https://m.media-amazon.com/images/I/51uRyZdV83L._SL75_.jpg https://m.media-amazon.com/images/I/51uRyZdV83L.jpg https://m.media-amazon.com/images/I/51xVS+-VlTL.jpg https://m.media-amazon.com/images/I/81v5NnoTFHL.jpg
List_price226.25
Mpns, PartNumber288-338 288338
Part_number, StrippedMpns288338
ProductTypeNameELECTRONIC_COMPONENT
Product_description<p> This Maximª WT 3000 PSI welded cylinder is crosstube mounted, and exceeds the highest standards. These Cylinders are designed for demanding applications and are built to ensure Maximum reliabilityand performance. Painted black. </p> <p> Intended Use: Double-acting applications ¥ Piston: Ductile iron ASTM A536 65-45-12 for excellent life ¥ Piston Lock Nut : Grade 8, high tensile zinc-plated ¥ Gland: Ductile iron ASTM A536 65-45-12 ¥ Tube: Precision honed steel ¥ Tube seal: Nitrile O-ring with Polytemp hytrel back-up ¥ Rod: High tensile ground & polished hard chrome plated rod ¥ Rod seal: Std PolyPak with B lip design (Polyurethane U-cup with Nitrile O-ring expander) ¥ Wiper: Polyurethane ¥ End Mounts: Cross-tubes ¥ Piston ID Seal: O-ring ¥ Piston OD seal: Hallite 755 piston seal with wear ring ¥ OD seal: Hallite 755 piston seal with wear ring </p> <p>3 Bore, 14 Stroke, 1.5 Rod Dia., 22 Retracted, 36 Extended, 21200 Column Load, SAE 8 Port Size, 1 Pin Dia.</p>
Product_site_launch_date2012-05-26T01:10:35.406Z
SizeOne Size
TitleMaxim WT Welded Cylinder: 3 Bore x 14 Stroke - 1.5 Rod Diameter, 3000 PSI with SAE #8 Port Size, Retracted: 22 and Extended: 36, 1" Pin Dia, 288338
TitleSourcelistings feed
Typeean upc
Unitpounds
VariantMAIN PT01
WebsiteDisplayGroupbiss_basic_display_on_website
WebsiteDisplayGroupNameBISS Basic
Width1425 1924 500 75

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG26667971611 @ $251.99
Grainger6FWX411
Raptor SuppliesAE8WBJ111 @ $443.81
AmazonB06XCQKKFX11
sustainablesupply.comC13783541-211 @ $399.57
grainger.caWWG6FWX4111 @ $314.54
simsupply.comZO-G26667971211 @ $278.48

Related on Amazon

As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.

Hyd Cylinder, 3 In Bore, 14 In Stroke
Brand: Maxim
<p> This Maximª WT 3000 PSI welded cylinder is crosstube mounted, and exceeds the highest standards. These Cylinders are designed for demanding applications and are built to ensure Maximum reliabilityand performance. Painted black. </p> <p> Intended Use: Double-acting applications ¥ Piston: Ductile iron ASTM A536 65-45-12 for excellent life ¥ Piston Lock Nut : Grade 8, high tensile zinc-plated ¥ Gland: Ductile iron ASTM A536 65-45-12 ¥ Tube: Precision honed steel ¥ Tube seal: Nitrile O-ring with Polytemp hytrel back-up ¥ Rod: High tensile ground & polished hard chrome plated rod ¥ Rod seal: Std PolyPak with B lip design (Polyurethane U-cup with Nitrile O-ring expander) ¥ Wiper: Polyurethane ¥ End Mounts: Cross-tubes ¥ Piston ID Seal: O-ring ¥ Piston OD seal: Hallite 755 piston seal with wear ring ¥ OD seal: Hallite 755 piston seal with wear ring </p> <p>3 Bore, 14 Stroke, 1.5 Rod Dia., 22 Retracted, 36 Extended, 21200 Column Load, SAE 8 Port Size, 1 Pin Dia.</p>
Details
  • 3 Bore, 14 Stroke, 1.5 Rod Dia., 22 Retract, 36 Extend, 21200 Load, SAE 8 Ports, 1 Pin
  • 3 Bore x 14 Stroke
  • 1.5 Rod Dia.
  • Bailey Part Number: 288338
Catalog
FeaturePrice For: Each Tie Rods: High Tensile Rod Seal: Polypak Finish: Black Piston Material: Ductile Iron Tubes: Precision Honed Steel Bore Dia. (In.): 3 Piston Rod: High Tensile Strength Item: Hydraulic Cylinder Temp. Range: -20 to 220 Type: Double Acting Welded Style Stroke (In.): 14 Rod Dia. (In.): 1-1/2 Port Size (SAE): # 8 Dimension E (In.): 0.750
CategoryIndustrial & Scientific
MPN288-338
Product groupBISS
Product typeELECTRONIC_COMPONENT
ManufacturerMAXIM
