Cylindrical Proximity Sensor, Inductive, 18 mm, Proximity Sensor Power Requirement 10 to 30V DC, Unshielded, Proximity Sensor Operating Frequency 300 Hz, Proximity Sensor Output Circuit Type 3 Wire NPN, Max. Detecting Distance 12 mm, Proximity Sensor Electrical Connection 4 Pin M12 Connector, Output Mode NO, IP Rating 65, 66, 67, 68, 69K, Case Material Brass White Bronze Coated, Length 60 mm, Operating Temp. Range -40 Degrees to 185 Degrees F, Max. Current Load 100mA

Ifm . IGS235

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerIfm
CategoryId, CategoryIdL44787
CategoryIdL123
CategoryIdL217009
CategoryIdL317027
CategoryL1Electrical Supplies
CategoryL2Industrial Control & Automation
CategoryL3Sensors
CategoryL4Proximity Sensors
DimensionUnitinch
GTIN, UPCNone
GraingerSku40KH26
UnitOfMeasureEA
Weight0.1
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginDE
height, width1.3
jsonUrlData924526ffbdad25e5923b
length5.5
moq, multiple, tierMinQty11
MPNIGS235
qtyInStock39
qtyInStockOverride-2
SKUG0528230
tierPrice130.59
urlhttps://www.zoro.com/ifm-prox-sensor-inductive-12mm-npn-no-qd-igs235/i/G0528230/
Length, Length (Straight Wireway)60 mm
Proximity Sensor Diameter18 mm
Dimensions [mm]M18 x 1 / L = 60
Proximity Sensor Style, ItemCylindrical Proximity Sensor
Proximity Sensing MethodInductive
Proximity Sensor Power Requirement10 to 30V DC
Proximity Sensor Output Circuit Type3 Wire NPN
Output ModeNO
Max Detecting Distance12 mm
Proximity Sensor Electrical Connection4 Pin M12 Connector
Shielded / UnshieldedUnshielded
Basic Proximity Sensor Case MaterialMetal
Proximity Sensor Operating Frequency300 Hz
Case MaterialBrass White Bronze Coated
Operating Temp Range-40 Degrees to 185 Degrees F
Max Current Load100mA
Description/Special FeaturesOverload And Short Protection
StandardsCUL Listed
IP Rating65, 66, 67, 68, 69K
Includes(2) Lock Nuts
EMCEN 61000-4-2 ESD 4 kV CD / 8 kV AD EN 61000-4-3 HF radiated 10 V/m EN 61000-4-4 Burst 2 kV EN 61000-4-6 HF conducted 10 V EN 55011 class B
ProtectionIP 65; IP 66; IP 67; IP 68; IP 69K

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG052823013911 @ $30.59
Walmart50450463111 @ $46.62
sustainablesupply.comC27845511-211 @ $47.15
simsupply.comCU-34304B4832361111 @ $52.58
Misumi USAIGS23511
simsupply.comZO-G052823012911 @ $39.71
