Dayton

Dayton . 71633695M

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameDayton
DimensionUnitinch
GraingerSku3M560
UPCNone
UnitOfMeasureEA
Voltage115V AC
Weight2.8
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
height3.7
jsonUrlData924526ffbdad25e5923b
length3.8
moq, multiple, tierMinQty1, Number of Speeds, Motor Service Factor, No of Speeds, Number of Shafts1
MPN71633695M
qtyInStock175
qtyInStockOverride-2
SKUG0366414
tierPrice159.73
urlhttps://www.zoro.com/dayton-hvac-motor-170-hp-1550-rpm-115v-33-71633695m/i/G0366414/
width8.4
Nameplate RPM1,550 RPM
Motor Enclosure DesignOpen Air-Over
HP1/70
RPM Range1,501-1,600
Motor BearingsSleeve
Motor Shaft DesignFlat
Motor Mounting Type, MountingStud
Voltage Compatibility115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Duty, Duty CycleContinuous
StandardsCSA Certified, UL Recognized
PhaseSingle
Motor ApplicationHVAC/R
Body Dia3 5/16 in
Ins ClassB
Motor DesignShaded Pole
Mounting Stud Location2/Both Ends
Motor Thermal ProtectionAuto
Hz60 Hz
Frame3.3
Max Ambient Temp40 Degrees C
Stud/Base Mtg Pattern2-7/8 in
Length Less Shaft3 7/8 in
Full Load Amps0.70
Motor Sub ApplicationDirect Drive Fan/Blower
ItemHVAC Motor
ApplicationOEM and Replacement Use In A Wide Variety of Fan and Blower
Mounting Pattern2-7/8
Shaft Length2 1/4 in
Cord Length16 in
Shaft Dia1/4 in
Motor Shaft RotationCWSE
Capacitor Required, Usable @ 208V, Usable @ 200VNo
Motor Mounting PositionAll Angle
Mounting Stud Pattern2 7/8 in
TypeOEM Replacement
Country of Origin (subject to change)Mexico

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG0366414117511 @ $59.73
Grainger3M56011
simsupply.comZO-G036641414211 @ $69.40
