Dayton

Dayton . 71632454M

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, Extra Product NameDayton
DimensionUnitinch
GraingerSku3M290
UPC00190735291689
UnitOfMeasureEA
Voltage115V AC
Weight, width4.8
WeightUnitlbs
cali_prop65_orglabel, cali_prop65_whtlabelFalse
countryOfOriginMX
height4.5
jsonUrlData924526ffbdad25e5923b
length8.8
moq, multiple, tierMinQty1, Number of Speeds, No of Speeds, Motor Service Factor, Number of Shafts1
MPN71632454M
qtyInStock446
qtyInStockOverride-2
SKUG2101251
tierPrice189.33
urlhttps://www.zoro.com/dayton-hvac-motor-120-hp-1550-rpm-115v-33-71632454m/i/G2101251/
Nameplate RPM1,550 RPM
Motor Enclosure DesignTotally Enclosed Fan-Cooled
HP1/20
RPM Range1,501-1,600
Shaft Dia5/16 in
ApplicationOEM and Replacement Use In A Wide Variety of Fan and Blower
Body Dia4 in
Stud/Base Mtg Pattern, Mounting Stud Pattern2 in x 2 in
Frame3.3
StandardsCSA Certified, UL Recognized
PhaseSingle
Duty, Duty CycleContinuous
Motor Thermal ProtectionAuto
Mounting Stud Location4/Shaft End
Ins ClassB
Cord Length12 in
Full Load Amps1.80
Shaft Length2 1/4 in
Motor Shaft RotationCCWSE
Length Less Shaft4 1/4 in
Max Ambient Temp40 Degrees C
Motor ApplicationHVAC/R
Motor Mounting Type, MountingStud
Mounting Pattern2 x 2
Motor DesignShaded Pole
ItemHVAC Motor
Voltage Compatibility115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Motor Shaft DesignFlat
Motor Sub ApplicationDirect Drive Fan/Blower
Motor BearingsBall
Hz60 Hz
Capacitor Required, Usable @ 208V, Usable @ 200VNo
Motor Mounting PositionAll Angle
TypeOEM Replacement
Country of Origin (subject to change)Mexico

Distributor offers

SellerSKUMOQIn stockMultiplePrices
ZoroG2101251144611 @ $89.33
simsupply.comZO-G210125114211 @ $103.73
