Dayton 6NZP6 | Hvac Motor 1/20 Hp 3000 Rpm 115v 3.3 | Raptor Supplies Worldwide

Heating, ventilating, and air conditioning motors can help you maximize the life and power of your HVAC systems. Use the right motor for the application to help maximize product life. Consider fan motor options for extra cooling power where you need it.<br /><br /> Item: HVAC Motor<br /> Motor Design: Permanent Split Capacitor<br /> HP: 1/20<br /> RPM Range: 1801-3000<br /> No. of Speeds: 1<br /> Voltage: 115<br /> Motor Shaft Rotation: CW/CCW<br /> Motor Enclosure Design: Open Air-Over<br /> Motor Mounting Type: Stud<br /> Shaft Dia.: 5/16"<br /> Shaft Length: 2-1/2"<br /> Number of Shafts: 1<br /> Motor Thermal Protection: Auto<br /> Nameplate RPM: 3000<br /> Phase: 1<br /> Motor Application: HVAC/R<br /> Motor Sub Application: Direct Drive Fan/Blower<br /> Frame: 3.3<br /> Motor Bearings: Ball<br /> Full Load Amps: 0.63<br /> Duty: Continuous<br /> Motor Service Factor: 1.00<br /> Hz: 60<br /> Body Dia.: 3.3"<br /> Ins. Class: B<br /> Max. Ambient Temp.: 40 Degrees C<br /> Length Less Shaft: 3-11/16"<br /> Mounting Stud Location: 4/Both Ends<br /> Stud/Base Mtg. Pattern: 2" x 2"<br /> Motor Shaft Design: Flat<br /> Application: Replaces 1/20 HP PSC and Less-Efficient Shaded Pole Motors in HVAC/R Applications<br /> Cord Length: 20"<br /> Includes: 4 MFD 370 VAC Capacitor<br /> Standards: UL Recognized (E37403), CSA Certified (244617)<br /> Mounting Pattern: 2 x 2<br /> Capacitor Required: Yes

HVAC Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/20 HP, Nameplate RPM 3,000, No. of Speeds 1, Voltage 115V AC, Full Load Amps 0.63, 3.3 Frame, Usable @ 208V No, Usable @ 200V No, Motor Thermal Protection Auto, 60 Hz Hz, Motor Service Factor 1, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Open Air-Over, Motor Mounting Type Stud, Motor Mounting Position All Angle, Number of Shafts 1
