Light-Duty Industrial Fan, Blade Dia. 30 in, Stationary, Oscillating, 2 Speeds, Voltage 115V AC, 1 Phase, CFM High 8200, CFM Low 7260, Air Velocity @ 20 Ft. 610/525 fpm, Motor HP 1/2 hp, Motor RPM 1100/850, Operating Amps 4.2/3.5, Fan Mounting Location Pedestal, Fan Accessory Style Standard, Fan RPM 1100/850, Sound Level 77 dBA, Max. Ambient Temp. 104 Degrees F, Hz 60 Hz, Watts 450/369, Motor Type Permanent Split Capacitor, Drive Type Direct Drive, Height 77 in, Width 27 1/4 in

This commercial air circulator is designed for moving air and cooling in clean, dry environments. It offers a high volume of air circulation at low sound levels for commercial applications including schools, greenhouses, and sporting events. It also offers a permanently lubricated motor with automatic reset thermal protection, and a stamped aluminum, 3-blade propeller and circulator head with locking tilt adjustment.<br /><br /> Item: Air Circulator<br /> Blade Dia.: 30"<br /> Mobile/Stationary: Stationary<br /> Oscillating: Yes<br /> Speeds: 2<br /> Voltage: 115<br /> Phase: 1<br /> CFM High: 8200<br /> CFM Low: 7260<br /> Air Velocity (FPM) @ 20 Ft.: 610/525<br /> Motor HP: 1/2<br /> Motor RPM: 1100/850<br /> Operating Amps: 4.2/3.5<br /> Fan Mounting Location: Pedestal<br /> Fan Accessory Style: Standard<br /> Fan RPM: 1100/850<br /> Environmental Applications: Commercial<br /> Assembled: No<br /> CFM/Watt: 18.22<br /> Air Velocity (FPM) @ 10 Ft.: 994/817<br /> Air Velocity (FPM) @ 40 Ft: 261/180<br /> Sound Level: 77dBA<br /> Max. Ambient Temp.: 104 Degrees F<br /> Hz: 60<br /> Watts: 450/369<br /> Motor Type: Permanent Split Capacitor<br /> Drive Type: Direct<br /> Motor Enclosure: Totally Enclosed Air-Over<br /> Motor Insulation: Class B<br /> Thermal Protection: Auto<br /> Bearing Type: Ball<br /> Height: Adj 61-3/4 to 77"<br /> Width: 27-1/4"<br /> Max. Depth: 27-1/4"<br /> Cord Length: 10 ft.<br /> Number of Blades: 3<br /> Blade Material: Aluminum<br /> Shaft Dia.: 5/8"<br /> Housing Material: Steel<br /> Guard Material: Steel<br /> Wire Guard Finish: Gloss Black Powder Coated<br /> Application: Spot Cooling and People Cooling<br /> Standards: UL/cUL<br /> Includes: Pedestal, Column and Mounting Hardware
