DAYTON . 5PV50

Product Type Suspended Horizontal Hydronic Wall & Ceiling Unit Heater, Air Flow Direction Horizontal, Heating Method Steam, Water, Output @ 2 PSI Steam 72,000 BtuH, Output @ 200 F Water 52,300 BtuH, Air Flow 1,100 cfm, Fan Phase 1, Overall Height 21 3/4 in, Overall Width 18 3/8 in, Overall Depth 11 1/16 in, Amperage 1.4 A, Coil Type Header, Connection Size 1 1/4 in, Connection Type Threaded Female NPT, Fan Diameter 14 in, Fan Guard Type OSHA Compliant Guard, Flow Rate 5.3 gpm, Frequency 60 Hz

The manufactured coil is submersion tested at 200 psi to assure coil is leak-free. Air flow is directed by manually adjustable louver blades. Header coil construction elements and heavy-wall tubing. Element tubes are brazed into the extruded header junctions. Pipe connection saddles are made of cast bronze and are brazed to the copper headers. Suitable for use in heating warehouses, manufacturing facilities, garages, and other large, open, nonexplosive, noncorrosive areas. ETL Certified and ETL rated to 150 lb. saturated steam at 366°F.<br /><br /> Item: Hydronic Unit Heater<br /> Heater Type: Water/Steam<br /> Fan Guard Type: OSHA<br /> Output @ 2 PSI Steam: 72,000 BtuH<br /> Output @ 200 F Water: 52,300 BtuH<br /> Air Flow: 1100 cfm<br /> Motor HP: 1/20<br /> Amps: 1.4<br /> Inlet/Outlet NPT: 1-1/4"<br /> Height: 21-3/4"<br /> Width: 18-3/8"<br /> Depth: 11-1/16"<br /> Air Flow Direction: Horizontal<br /> Coil Type: Header<br /> Heater Voltage: 120VAC<br /> Hz: 60<br /> Phase: 1<br /> Max. Operating PSI: 75<br /> Max. Operating Temp.: 320 Degrees F<br /> Motor Enclosure: Totally Enclosed<br /> Mounting Height: 10 ft.<br /> Standards: ETL Certified
