135 Wide Land Parabolic Jobber Length Drill Chicago-Latrobe 150WLP-TC TiCN HSS RHS/RHC 13/64
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Zoro | G2966494 | 1 | 119 | 1 | 1 @ $9.75 |
 Zoro | G2909225 | 1 | 271 | 1 | 1 @ $9.55 |
| 4CNL5 | 1 | 119 | 1 | 1 @ $15.69 | |
| Grainger | 2THY4 | 1 | 1 | ||
| 46786 | 1 | 1 | 1 @ $9.42 | ||
 bscsource.com | 46786 | 1 | 1 | 1 @ $13.09 | |
 Global Industrial | WBB2547955 | 6 | -2 | 6 | 1 @ $8.70 |
| sustainablesupply.com | C1463667 | 1 | -2 | 1 | 1 @ $12.03 |
| Guardian | 81193161 | 1 | 1 | ||
| 82136078 | 1 | -2 | 1 | 1 @ $16.36 | |
| 42013 | 15 | 12 | 1 @ $7.14 | ||
| 46786 | 11 | -2 | 6 | 1 @ $9.49 | |
| 46786 | 1 | -2 | 1 | 1 @ $7.79 | |
| 81193161 | 1 | -2 | 1 | 1 @ $14.15 | |
| 82136078 | 1 | -2 | 1 | 1 @ $13.30 | |
 MRO Supply | 6129387 | 1 | 1 | 1 @ $7.80 | |
 MRO Supply | 6127720 | 1 | 1 | 1 @ $7.05 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
Chicago Latrobe 550 Cobalt Steel Jobber Length Drill Bit, Gold Oxide Coated, Round Shank, 135 Degree Split Point, Letter Size P (Pack of 1)
Brand: Chicago Latrobe
Details
- Jobber length drill bit has a midrange drilling depth for general-purpose applications
- Cobalt steel provides extended tool life compared to high-speed steel drill bits when drilling hard materials
- Gold oxide finish lubricates and provides wear resistance on ferrous materials
- Self-centering 135-degree split point penetrates hard material without a pilot hole and produces small chips to reduce clogging
- Extra thick web provides increased strength and rigidity compared to standard drill bits
- Made in the USA
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | DRILL_BITS |
| Model | 46786 |
| Part number | 46786 |
| Items per pack | 1 |
| Label | CHICAGO-LATROBE |
| Manufacturer | CHICAGO-LATROBE |
Jobber Bit, 13/64In, High Speed Steel
Brand: Chicago Latrobe
'Jobber Drill Bit, Fractional Inch, Drill Bit Size 13/64 In., Decimal Equivalent 0.2031, Drill Bit Point Angle 135 Degrees , Drill Bit Material High Speed Steel, Drill Bit Finish TiCN, Flute Type Parabolic, Coolant Through No, Cutting Direction Right Hand, Grade High Performance, Overall Length 3-5/8 In., Shank Dia. 13/64 In., Flute Length 2-7/16 In., Point Type Notch Point, List Number 150WLPN, For Alloy, Carbon Free Machining And Tool Steels'
Details
- Price For: Each Flute Type: Parabolic Drill Bit Grouping: Drill Bit List Number: 150WLPN Drill Bit Size: 13/64" Shank Dia.: 13/64" Point Type: Notch Point Drill Bit Finish: TiCN Overall Length: 3-5/8" Drill Bit Point Angle: 135 Degrees Item: Jobber Drill Bit Drill Bit Dimension Type: Fractional Inch Decimal Equivalent: 0.2031 Drill Bit Material: High Speed Steel
- Coolant Through: No Flute Length: 2-7/16" Cutting Direction: Right Hand Country of Origin (subject to change): United States
Listing
| Product group | BISS |
|---|---|
| Product type | ELECTRONIC_COMPONENT |
| Part number | 42013 |
| Label | CHICAGO-LATROBE |
| Manufacturer | CHICAGO-LATROBE |
Catalog
| Feature | Price For: Each Flute Type: Parabolic Drill Bit Grouping: Drill Bit List Number: 150WLPN Drill Bit Size: 13/64" Shank Dia.: 13/64" Point Type: Notch Point Drill Bit Finish: TiCN Overall Length: 3-5/8" Drill Bit Point Angle: 135 Degrees Item: Jobber Drill Bit Drill Bit Dimension Type: Fractional Inch Decimal Equivalent: 0.2031 Drill Bit Material: High Speed Steel |
|---|---|
| Category | Tools & Home Improvement |
| MPN | 42013 |
| Product group | BISS |
| Product type | ELECTRONIC_COMPONENT |
| Manufacturer | CHICAGO-LATROBE |
Chicago Latrobe 150WLPN High-Speed Steel Jobber Length Drill Bit, TiCN Coated, Round Shank, Wide Parabolic Flute, 135 Degree Notched Point, 13/64" Size (Pack of 12)
Brand: Chicago Latrobe
Details
- Parabolic jobber length drill bit has a long reach for deep drilling applications
- High-speed steel (HSS) provides hardness for wear resistance
- Titanium carbon nitride (TiCN) coating is harder than TiN for better wear resistance and is recommended when drilling ferrous and nonferrous materials
- Self-centering 135-degree notched point penetrates material without a pilot hole more easily than a conventional point, and maintains a sharp cutting edge
- Wide parabolic flutes increase coolant flow and chip evacuation, and are stronger and more rigid than standard parabolic flutes for deep drilling in difficult-to-machine materials
- Made in the USA
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | DRILL_BITS |
| Model | 42013 |
| Part number | 42013 |
| Items per pack | 12 |
| Label | CHICAGO-LATROBE |
| Manufacturer | CHICAGO-LATROBE |
P 4-5/8" Cobalt 135 Deg. Jobber Length Drill Bit
Brand: Chicago Latrobe
Listing
| Product group | BISS Basic |
|---|---|
| Product type | DRILL_BITS |
| Part number | 46786 |
| Label | CHICAGO-LATROBE |
| Manufacturer | CHICAGO-LATROBE |
Jobber Bit, P, Cobalt Steel
Brand: Chicago Latrobe
'Jobber Drill Bit, Letter, Drill Bit Size P, Decimal Equivalent 0.3230, Drill Bit Point Angle 135 Degrees , Drill Bit Material Cobalt Steel, Drill Bit Finish Straw/Bronze, Flute Type Spiral, Coolant Through No, Cutting Direction Right Hand, Grade Heavy Duty, Overall Length 4-5/8 In., Shank Dia. 0.3230 In., Flute Length 3-5/16 In., Point Type Split Point, List Number 550, Standards National Aerospace Standards (NAS) 907, Type J, For Stainless Steel, Tool Steel, Alloy Steel And Titianium'
Details
- Price For: Each Drill Bit Material: Cobalt Steel Flute Type: Spiral Standards: National Aerospace Standards (NAS) 907, Type J Drill Bit Grouping: Drill Bit Point Type: Split Point List Number: 550 Drill Bit Finish: Straw/Bronze Drill Bit Dimension Type: Letter Cutting Direction: Right Hand Item: Jobber Drill Bit Coolant Through: No Drill Bit Point Angle: 135 Degrees
- List Number: 550 Point Type: Split Point Decimal Equivalent: 0.3230 Flute Length: 3-5/16" Drill Bit Size: P Shank Dia.: 0.3230" Overall Length: 4-5/8" Country of Origin (subject to change): United States
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS Basic |
| Product type | DRILL_BITS |
| Model | 46786 |
| Part number | 46786 |
| Items per pack | 1 |
| Label | CHICAGO-LATROBE |
| Manufacturer | CHICAGO-LATROBE |
Catalog
| Feature | Price For: Each Drill Bit Material: Cobalt Steel Flute Type: Spiral Standards: National Aerospace Standards (NAS) 907, Type J Drill Bit Grouping: Drill Bit Point Type: Split Point List Number: 550 Drill Bit Finish: Straw/Bronze Drill Bit Dimension Type: Letter Cutting Direction: Right Hand Item: Jobber Drill Bit Coolant Through: No Drill Bit Point Angle: 135 Degrees |
|---|---|
| Category | Tools & Home Improvement |
| MPN | 46786 |
| Product group | BISS |
| Product type | MECHANICAL_COMPONENTS |
| Manufacturer | CHICAGO-LATROBE |
Chicago-Latrobe 42013 150WLP-TC Jobber Length Drill Bit, 13/64 in Drill - Fraction, 0.2031 in Drill - Decimal Inch, 135 deg Point, HSS, TiCN Coated (Each)
Brand: Chicago Latrobe
Chicago-Latrobe Jobber Length Drill Bit, Series: 150WLP-TC, Imperial, 13/64 in Drill - Fraction, 0.2031 in Drill - Decimal Inch, 3-5/8 in Overall Length, 7XD Cutting Depth, 2 Flutes, Wide Land Parabolic Flute, 2-7/16 in Flute Length, 13/64 in Dia x 1-3/16 in L Shank, Straight Shank, 135 deg Point, Split Point, Right Hand Cutting Direction, HSS Cutting Edge, No Through Coolant, HSS, TiCN Coated, Applicable Materials: Alloy Steel, Carbon Steel, Free Machining Steel and Tool Steel
Greenfield 46786 550 LET-P (46786) (6/Each)
Brand: Chicago Latrobe
GREENFIELD 46786 550 LET-P (46786) (6/each)
