SEN0256 DFRobot | Sensors, Transducers | DigiKey
Gallery
Attributes
Distributor offers
| Seller | SKU | MOQ | In stock | Multiple | Prices |
|---|---|---|---|---|---|
| Digi-Key | 10279716 | 1 | 7 | 1 | 1 @ $102.35 |
Related on Amazon
As an Amazon Associate, we earn from qualifying purchases. (paid link) CERTAIN CONTENT THAT APPEARS ON THIS SITE COMES FROM AMAZON. THIS CONTENT IS PROVIDED 'AS IS' AND IS SUBJECT TO CHANGE OR REMOVAL AT ANY TIME.
DFRobot TS01 Non-Contact Industrial Analog Infrared Temperature Sensor (-70℃~380℃, IP65, 0-3V)
Brand: DFROBOT
<b>DFRobot TS01 Non-Contact Analog Infrared Temperature Sensor (-70℃~380℃, IP65, 0-3V)</b><br><br><b>Introduction</b><br>This TS01 IR Thermal Sensor 0-3V is an infrared thermometer designed for non-contact temperature measurement, it has similar functions of mlx90614 IR temperature sensor.<br><br><b>Features</b><br>Non-contact Temperature Measurement<br>Operating Temperature Range of Industrial Grade<br>Analog Voltage Output<br>Mental Packaging<br><br><b>Specification</b><br>Supply Voltage: 5.0~24V DC<br>Operating Current: 20mA<br>Signal Output: analog voltage 0~3V<br>Operating Temperature: -40℃~85℃<br>Measuring Temperature: -70℃~380℃<br>Accuracy: ±0.5℃~±4℃<br>FOV: 5°<br>Defense Grade: IP65<br>Probe Diameter: 15.4 mm/0.61”<br>Probe Length: 78 mm/3.07”<br>Cable Length: 1.5m/59.06”<br>Interface Type: DuPont 3Pin+DuPont 1Pin<br><br><b>Shipping list</b><br>TS01 Non-Contact Analog Infrared Temperature Sensor (-70℃~380℃, IP65, 0-3V) x1
Details
- DFRobot TS01 IR Thermal Sensor is a remote non-contact sensor, which can be used to measure the infrared intensity of the object so as to calculate its surface temperature without touching. The built-in temperature compensation for the sensor greatly ensures the accuracy of the temperature measurement.
- The all mental package of the sensor makes it able to protect against impact, water, dust and so on. Given stable output data, this temperature sensor can exhibit a much better measurement performance than most other similar products on the market. The product has been calibrated in wide temperature range before leaving the factory.
- With an operating temperature of -40℃-85℃, the sensor can be used to measure the temperature of -70℃~380℃ while providing a maximum accuracy of 0.5°C.
- An optical filter (long-wave pass ) that cuts off the visible and near infra-red radiant flux is integrated in the package to provide ambient and sunlight immunity. Its FOV is small as 5°， which means for a heat source of 10cm outer diameter, the maximum measuring distance of the sensor can reach up to 116cm.
- Any technical issues after purchase please contact with our tech-support team. Product wiki: wiki.dfrobot.com/TS01_IR_Thermal_Sensor_(0-3V)_SKU_SEN0256
Listing
| Binding | Misc. |
|---|---|
| Product group | BISS |
| Product type | PRECISION_MEASURING |
| Model | SEN0256 |
| Part number | SEN0256 |
| Label | DFROBOT |
| Manufacturer | DFROBOT |
