HELUKABEL 10044 | Wire; JZ-500; 12x0,75mm2; unshielded; 300V,500V; Cu; stranded; grey

HELUKABEL . 10044

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerHELUKABEL
CategoryL1Wires and Cables
CategoryL2Cables
CategoryL3Multicore Cables
CategoryL4Multicore Cables - Unshielded
DimensionUnitmm
Extra Product NameHELUKABEL 10044 | Wire; JZ-500; 12x0,75mm2; unshielded; 300V,500V; Cu; stranded; grey
atoms1
diameter, length, width10.1
jsonUrlData03da00884e604e883cb7dd3569511343.
jsonUrlData2350e48d0f2fcced09744
keywordsHELUKABEL, 10044, OZ500/12X0.75, Wires and Cables, Cables, Multicore Cables, Multicore Cables - Unshielded
length_Attrib, width_AttribCable external diameter
moq, multiple, tierMinQty1, Flexibility class5
MPN10044
qtyInStock215
SKUOZ500/12X0.75
snippetHELUKABEL 10044 | Wire; JZ-500; 12x0,75mm2; unshielded; 300V,500V; Cu; stranded; gre
tierMinQty225
tierMinQty350
tierMinQty4100
tierPrice13.69
tierPrice23.23
tierPrice32.73
tierPrice42.54
Type of wirecontrol cable
Kind of wireJZ-500
Shield structureunshielded
Rated voltage300V/
Wire insulation materialPVC
Kind of coreCu
Core structurestranded
Number of cores12
Core section0.75mm
Core markingblack, numbered
Insulation colourgrey
Cable external diameter10.1mm
Kind of materialno flame propagation
Operating temperature-40...80?C
Resistance tomost of chemical compounds,
Earth corenone
CPR standardE
Cable applicationassembly line tools,

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEOZ500/12X0.75521555 @ $3.69, 25 @ $3.23, 50 @ $2.73, 100 @ $2.54
