OMRON OCB G5Q-14-EU 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10A

OMRON OCB . G5Q-14-EU 24VDC

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerOMRON OCB
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Miniature Electromagnetic Relays
Extra Product NameOMRON OCB G5Q-14-EU 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10A
atoms, moq, multiple, tierMinQty11
jsonUrlData303a0aff3ef4e9d2b39f8e76b0e00553.
jsonUrlData292fa60bd5216408afb62
keywordsOMRON OCB, G5Q-14-EU 24VDC, G5Q-14-EU-24DC
MPNG5Q-14-EU 24VDC
qtyInStock1314
SKUG5Q-14-EU-24DC
snippetOMRON OCB G5Q-14-EU 24VDC | Relay: electromagnetic; SPDT; Ucoil: 24VDC; Icontacts max: 10
tierMinQty25
tierMinQty325
tierMinQty4120
tierMinQty5520
tierPrice11.74
tierPrice21.59
tierPrice31.23
tierPrice41.15
tierPrice51.07
Type of relayelectromagnetic
Contacts configurationSPDT
Rated coil voltage24V DC
Contact current max10A
AC contacts rating @R10A / 250V AC
DC contacts rating @R5A / 30V DC
Switched voltagemax. 30V DC,
Relay variantminiature
MountingPCB
Coil resistance1.44k?
Operate time10ms
Body dimensions20.3x10.3x15.8mm
Release time5ms
Coil power consumption400mW
Operating temperature-40...85?C
Relay seriesG5Q-EU
Contact resistance100m?
Terminal pitch2.54mm
Coil current16.7mA
Enclosure descriptionhermetic seal

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEG5Q-14-EU-24DC1131411 @ $1.74, 5 @ $1.59, 25 @ $1.23, 120 @ $1.15, 520 @ $1.07
