OMRON OCB G6KU-2F-Y 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; SMD

OMRON OCB . G6KU-2F-Y 24VDC

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerOMRON OCB
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Miniature Electromagnetic Relays
Extra Product NameOMRON OCB G6KU-2F-Y 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; SMD
atoms, moq, multiple, tierMinQty11
jsonUrlData3e700d98ad70623aa219cd34ea26f027.
jsonUrlData220fe98509a867de053b0
keywordsOMRON OCB, G6KU-2F-Y 24VDC, G6KU-2F-Y-24DC, Relays and Contactors, Relays, Electromagnetic Relays, Miniature Electromagnetic Relays
MPNG6KU-2F-Y 24VDC
qtyInStock455
SKUG6KU-2F-Y-24DC
snippetOMRON OCB G6KU-2F-Y 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; SM
tierMinQty25
tierMinQty325
tierMinQty4100
tierMinQty5500
tierPrice14.53
tierPrice24.12
tierPrice33.2
tierPrice42.99
tierPrice52.79
Type of relayelectromagnetic
Contacts configurationDPDT
Rated coil voltage24V DC
Contact current max1A
AC contacts rating @R0.3A / 125V AC
DC contacts rating @R1A / 30V DC
Switched voltagemax. 60V DC,
Relay variantbistable,
MountingSMD
Coil resistance5.22k?
Operate time, Release time3ms
Body dimensions10x6.5x5.2mm
Coil power consumption100mW
Operating temperature-40...70?C
Relay seriesG6K
Contact resistance100m?
Terminal pitch3.2mm
Coil current4.6mA
Designsingle coil

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEG6KU-2F-Y-24DC145511 @ $4.53, 5 @ $4.12, 25 @ $3.20, 100 @ $2.99, 500 @ $2.79
