OMRON OCB G6K-2P 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; PCB

OMRON OCB . G6K-2P 24VDC

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerOMRON OCB
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Miniature Electromagnetic Relays
Extra Product NameOMRON OCB G6K-2P 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; PCB
atoms, moq, multiple, tierMinQty11
jsonUrlData8ef2726d19f848ccffa3c5d9f713d145.
jsonUrlData2aba685757e24b8673a0c
keywordsOMRON OCB, G6K-2P 24VDC, G6K-2P-24DC, Relays and Contactors, Relays, Electromagnetic Relays, Miniature Electromagnetic Relays
MPNG6K-2P 24VDC
qtyInStock0
SKUG6K-2P-24DC
snippetOMRON OCB G6K-2P 24VDC | Relay: electromagnetic; DPDT; Ucoil: 24VDC; Icontacts max: 1A; PC
tierMinQty25
tierMinQty325
tierMinQty4100
tierPrice14.72
tierPrice24.53
tierPrice34.14
tierPrice43.94
Type of relayelectromagnetic
Contacts configurationDPDT
Rated coil voltage24V DC
Contact current max1A
AC contacts rating @R0.3A / 125V AC
DC contacts rating @R1A / 30V DC
Switched voltagemax. 60V DC,
Relay variantsubminiature
MountingPCB
Coil resistance5.22k?
Operate time, Release time3ms
Body dimensions10x6.5x5.2mm
Coil power consumption100mW
Operating temperature-40...70?C
Relay seriesG6K
Contact resistance100m?
Terminal pitch2.54mm
Coil current4.6mA

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEG6K-2P-24DC111 @ $4.72, 5 @ $4.53, 25 @ $4.14, 100 @ $3.94
