OMRON OCB G6K-2F 5VDC | Relay: electromagnetic; DPDT; Ucoil: 5VDC; Icontacts max: 1A; SMD

OMRON OCB . G6K-2F 5VDC

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerOMRON OCB
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Miniature Electromagnetic Relays
Extra Product NameOMRON OCB G6K-2F 5VDC | Relay: electromagnetic; DPDT; Ucoil: 5VDC; Icontacts max: 1A; SMD
atoms, moq, multiple, tierMinQty11
jsonUrlData5712c7e891275d573c24c39afd631886.
jsonUrlData2521278d1db07c44fadb6
keywordsOMRON OCB, G6K-2F 5VDC, G6K-2F-5DC, Relays and Contactors, Relays, Electromagnetic Relays, Miniature Electromagnetic Relays
MPNG6K-2F 5VDC
qtyInStock0
SKUG6K-2F-5DC
snippetOMRON OCB G6K-2F 5VDC | Relay: electromagnetic; DPDT; Ucoil: 5VDC; Icontacts max: 1A; SM
tierMinQty25
tierMinQty325
tierMinQty4100
tierMinQty5500
tierPrice13.62
tierPrice23.29
tierPrice32.55
tierPrice42.38
tierPrice52.22
Type of relayelectromagnetic
Contacts configurationDPDT
Rated coil voltage5V DC
Contact current max1A
AC contacts rating @R0.3A / 125V AC
DC contacts rating @R1A / 30V DC
Switched voltagemax. 60V DC,
Relay variantsubminiature
MountingSMD
Coil resistance237?
Operate time, Release time3ms
Body dimensions10x6.5x5.2mm
Coil power consumption100mW
Operating temperature-40...70?C
Relay seriesG6K
Contact resistance100m?
Terminal pitch2.54mm
Coil current21.1mA

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEG6K-2F-5DC111 @ $3.62, 5 @ $3.29, 25 @ $2.55, 100 @ $2.38, 500 @ $2.22
