ABB - A50-30-11-81 - Contactor,NEMA,3 Pole,54A,24VAC@60Hz,24VAC@50Hz Coil,DIN Rail/Panel Mount - Allied Electronics & Automation, part of RS Group

ABB A50-30-11-81 A LINE, (30-75), 3-POLE A50,3P CONTR,24/50/60

ABB A-Line non-reversing 3-pole contactor has 24 VAC coil voltage and 54 A load current with a power rating of 40 hp at 460/480 VAC 3-phase. Brand Name|ABB#MFR Part Number|A50-30-11-81#UPC|662019880471#UNSPSC|39121529#Item|Contactor#Type|Non-Reversing#Series|A-Line, A50#Coil Voltage|24 VAC#Full Load Current|54 A at 3-Phase, 80 A at 1-Phase#Power Rating|40 hp at 460/480 VAC 3-Phase, 20 hp at 230/240 VAC 3-Phase, 3 hp at 115 VAC 1-Phase, 20 hp at 230/240 VAC 1-Phase, 15 hp at 200/208 VAC 3-Phase, 50 hp at 575/600 VAC 3-Phase#Number of Poles|3#Frequency Rating|50/60 Hz#Contact Form|1 NO - 1 NC#Terminal Type|Screw#Enclosure Type|NEMA 00 - 3#Mounting Type|Snap-On DIN-Rail#Dimensions|4.33 in Height x 3.22 in Width x 4.25 in Depth#Standard/Approvals|CE Certified, CSA LR56745, IEC Approved, UL E39231#Application|For controlling 3-phase motors and for controlling power circuits corresponding to their operating characteristics up to 690 and even 1000 VAC and 440 VDC
