RELPOL RM93-1021-25-S006 | Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 8A; 8A/250VAC; PCB

RELPOL . RM93-1021-25-S006

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerRELPOL
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Miniature Electromagnetic Relays
Extra Product NameRELPOL RM93-1021-25-S006 | Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 8A; 8A/250VAC; PCB
atoms, moq, multiple1
jsonUrlData28f84d1a354915518b62a56b4d46e6ae.
jsonUrlData260dee092e6e8fcac7d02
keywordsRELPOL, RM93-1021-25-S006, RM93-Z-6V-S, Relays and Contactors, Relays, Electromagnetic Relays, Miniature Electromagnetic Relays
MPNRM93-1021-25-S006
qtyInStock0
SKURM93-Z-6V-S
snippetRELPOL RM93-1021-25-S006 | Relay: electromagnetic; SPST-NO; Ucoil: 6VDC; 8A; 8A/250VAC; PC
Type of relayelectromagnetic
Contacts configurationSPST-NO
Rated coil voltage6V DC
Contact current max8A
AC contacts rating @R8A / 250V AC
DC contacts rating @R8A / 24V DC
Switched voltagemax. 250V DC,
Relay variantminiature,
MountingPCB
Coil resistance80?
Coil voltage min4V DC
Coil voltage max9.4V DC
Operate time7ms
Body dimensions28x12x26mm
Release time2ms
Coil power consumption0.5W
Operating temperature-40...70?C
Relay seriesRM93
Contact resistance100m?
Terminal pitch2.5mm

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMERM93-Z-6V-S11
