RELPOL RM93-1011-25-1048 | Relay: electromagnetic; SPDT; Ucoil: 48VDC; 8A; 8A/250VAC; 8A/24VDC

RELPOL . RM93-1011-25-1048

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerRELPOL
Extra Product NameRELPOL RM93-1011-25-1048 | Relay: electromagnetic; SPDT; Ucoil: 48VDC; 8A; 8A/250VAC; 8A/24VDC
atoms, moq, multiple1
jsonUrlDatad0c05d9971c74d858363971e32a876da.5
jsonUrlData2655db78ff5fd53cbbcb1
MPNRM93-1011-25-1048
qtyInStock0
SKURM93-P-48V
snippetRELPOL RM93-1011-25-1048 | Relay: electromagnetic; SPDT; Ucoil: 48VDC; 8A; 8A/250VAC; 8A/24VD
Type of relayelectromagnetic
Contacts configurationSPDT
Rated coil voltage48V DC
Contact current max8A
AC contacts rating @R8A / 250V AC
DC contacts rating @R8A / 24V DC
Switched voltagemax. 250V DC,
Relay variantminiature
MountingPCB
Coil resistance3.2k?
Coil voltage min31V DC
Coil voltage max70V DC
Operate time7ms
Body dimensions28x12x26mm
Release time2ms
Coil power consumption0.8W
Operating temperature-40...70?C
Relay seriesRM93
Contact resistance100m?
Terminal pitch2.5mm
