RELPOL RG25-1022-28-3230 | Relay: electromagnetic; DPST-NO; Ucoil: 230VAC; Icontacts max: 25A

RELPOL . RG25-1022-28-3230

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerRELPOL
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Industrial Electromagnetic Relays
Extra Product NameRELPOL RG25-1022-28-3230 | Relay: electromagnetic; DPST-NO; Ucoil: 230VAC; Icontacts max: 25A
atoms, moq, multiple1
jsonUrlData3a0904caaaa585908155f4f99ce6d305.
jsonUrlData2d1f21d378a90f1dcf32a
keywordsRELPOL, RG25-1022-28-3230, RG25-230VAC
MPNRG25-1022-28-3230
qtyInStock0
SKURG25-230VAC
snippetRELPOL RG25-1022-28-3230 | Relay: electromagnetic; DPST-NO; Ucoil: 230VAC; Icontacts max: 25
Type of relayelectromagnetic
Contacts configurationDPST-NO
Rated coil voltage230V AC
Contact current max25A
AC contacts rating @R25A / 400V AC
DC contacts rating @R25A / 24V DC
Switched voltagemax. 250V DC,
Relay variantindustrial
Mountingfor DIN rail mounting
Coil voltage min161V AC
Coil voltage max253V AC
Relay seriesRG25
Operating temperature-25...85?C
Body dimensions26x53.7x75.5mm
Coil resistance6.8k?
Operate time, Release time20ms
Contact resistance100m?
Contact materialAgCdO
Coil power consumption3VA
Leadsscrew terminals
Max surge current40A
