RELPOL R15-2012-23-5230-WT | Relay: electromagnetic; DPDT; Ucoil: 230VAC; Icontacts max: 20A

RELPOL . R15-2012-23-5230-WT

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerRELPOL
CategoryL1Relays and Contactors
CategoryL2Relays
CategoryL3Electromagnetic Relays
CategoryL4Industrial Electromagnetic Relays
Extra Product NameRELPOL R15-2012-23-5230-WT | Relay: electromagnetic; DPDT; Ucoil: 230VAC; Icontacts max: 20A
atoms, moq, multiple, tierMinQty11
jsonUrlDataa9a4dd46bcc8521435ff15e746c7a47a.
jsonUrlData21f76f9c6f515f1cceda7
keywordsRELPOL, R15-2012-23-5230-WT, R15-2P-230VAC
MPNR15-2012-23-5230-WT
qtyInStock78
SKUR15-2P-230VAC
snippetRELPOL R15-2012-23-5230-WT | Relay: electromagnetic; DPDT; Ucoil: 230VAC; Icontacts max: 20
tierMinQty25
tierMinQty325
tierMinQty4100
tierPrice114.74
tierPrice214.31
tierPrice313.87
tierPrice411.71
Type of relayelectromagnetic
Contacts configurationDPDT
Rated coil voltage230V AC
Contact current max20A
AC contacts rating @R10A / 250V AC
DC contacts rating @R10A / 24V DC
Switched voltagemax. 250V DC,
Relay variantindustrial
Mountingsocket
Relay seriesR15
Operating temperature-40...55?C
Body dimensions35x35x54.5mm
Coil resistance7.08k?
Contact resistance100m?
Coil power consumption1.6VA
Leadsstud terminals
Number of pins8
Electrical connectionround socket
Kind of connectoroctal
Related itemsGOP8,
OEM number804299

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMER15-2P-230VAC17811 @ $14.74, 5 @ $14.31, 25 @ $13.87, 100 @ $11.71
