Square D - LAL26175 - Molded Case Circuit Breaker, 2-Pole, 600V 175A, LAL Series - RS

<p>Circuit Breaker, Amps 175, Number of Poles 2, Circuit Breaker Type Standard, AC Voltage Rating 600VAC, DC Voltage Rating 250VDC, For Use With -, Series LAL, Trip Type Thermal Magnetic, Terminal Connection Lug, Max. AIR Rating 22 kA, Phase Connection -, Mounting Free Standing, Height 11.00 In., Width 6.00 In., Depth 5.80 In., Min. Wire Size 1 AWG (Al), Max. Wire Size (1) 600 kcmil (Al) or (2) 250 kcmil (Al), Instantaneous Trip Adjustable, High Amp Trip Setting 1750A, Low Amp Trip Setting 875A</p><p><b>Specifications: </b><ul><li>Standards: UL listed, CSA certified</li><li>Amps: 175</li><li>Phase Connection: -</li><li>Terminal Connection: Lug</li><li>Instantaneous Trip: Adjustable</li><li>Mounting: Free Standing</li><li>Item: Circuit Breaker</li><li>Width: 6.00"</li><li>Circuit Breaker Type: Standard</li><li>Low Amp Trip Setting: 875A</li><li>Min. Wire Size: 1 AWG (Al)</li><li>Height: 11.00"</li><li>Number of Poles: 2</li><li>DC Voltage Rating: 250VDC</li><li>High Amp Trip Setting: 1750A</li><li>Depth: 5.80"</li><li>AC Voltage Rating: 600VAC</li><li>Frame Size: 400A/LA</li><li>Phase: 1</li><li>For Use With: -</li><li>Series: LAL</li><li>Max. AIR Rating: 22 kA</li><li>Max. Wire Size: (1) 600 kcmil (Al) or (2) 250 kcmil (Al)</li><li>Trip Type: Thermal Magnetic</li></ul></p>
