Square D - QDL32110 - Molded Case Circuit Breaker, 3-Pole, 240V 110A, QDL Series - Allied Electronics & Automation, part of RS Group

<p>Circuit Breaker, Amps 110, Number of Poles 3, Circuit Breaker Type Standard, AC Voltage Rating 240VAC, DC Voltage Rating Not Rated, For Use With -, Series QD, Trip Type Thermal Magnetic, Terminal Connection Lug, Max. AIR Rating 25 kA, Phase Connection ABC, Mounting Free Standing, Height 6.47 In., Width 4.50 In., Depth 3.93 In., Min. Wire Size 4 AWG, Max. Wire Size 300 kcmil, Instantaneous Trip Fixed, High Amp Trip Setting 2400A, Low Amp Trip Setting 1200A, Frame Size 250A/QD</p><p><b>Specifications: </b><ul><li>Phase: 3</li><li>Amps: 110</li><li>DC Voltage Rating: Not Rated</li><li>Low Amp Trip Setting: 1200A</li><li>Mounting: Free Standing</li><li>Phase Connection: ABC</li><li>Circuit Breaker Type: Standard</li><li>Width: 4.50"</li><li>Min. Wire Size: 4 AWG</li><li>Instantaneous Trip: Fixed</li><li>For Use With: -</li><li>Height: 6.47"</li><li>AC Voltage Rating: 240VAC</li><li>Max. Wire Size: 300 kcmil</li><li>Depth: 3.93"</li><li>Max. AIR Rating: 25 kA</li><li>Trip Type: Thermal Magnetic</li><li>Item: Circuit Breaker</li><li>Standards: UL Listed, CSA Certified, CE Marked, IEC</li><li>Frame Size: 250A/QD</li><li>Number of Poles: 3</li><li>High Amp Trip Setting: 2400A</li><li>Terminal Connection: Lug</li><li>Series: QD</li></ul></p>
