Vishay Zener Diode, 5.1V, 0.3W, Sot-23 - BZX84B5V1-E3-08

BZX84-V-Series 300 mW 5.1 V Surface Mount Small Signal Zener Diode - SOT-23-3 ***** For more information refer to the specification sheet located in the 'Downloads' section below the image *****

ZENER DIODE, 5.1V, 0.3W, SOT-23; Zener Voltage Vz Typ:5.1V; Power Dissipation Pd:300mW; Diode Case Style:SOT-23; Zener Tolerance ±:2%; No. of Pins:3Pins; Operating Temperature Max:150°C; Product Range:BZX84-Series RoHS Compliant: Yes

EU RoHS: Compliant ECCN (US): EAR99 Part Status: Active HTS: 8541.10.00.50 Automotive: No PPAP: No Type: Voltage Regulator Configuration: Single Nominal Zener Voltage (V): 5.1 Zener Voltage Tolerance: 2% Maximum Power Dissipation (mW): 300 Test Current (mA): 5 Maximum Reverse Leakage Current (uA): 2 Maximum Zener Impedance (Ohm): 60 Maximum Power Dissipation @ 25C (mW): 300 Minimum Operating Temperature (°C): -55 Maximum Operating Temperature (°C): 150 Supplier Temperature Grade: Commercial Maximum Zener Voltage (V): 5.2 Typical Voltage Temperature Coefficient: 0.005%/°C Minimum Zener Voltage (V): 5 Packaging: Tape and Reel Product Weight (g): 0.0088 Supplier Package: SOT-23 Pin Count: 3 Standard Package Name: SOT Mounting: Surface Mount Package Height: 1.05(Max) Package Length: 3.1(Max) Package Width: 1.43(Max) PCB changed: 3 Lead Shape: Gull-wing
