AEMC 275HVD User Selectable High Voltage Detector

AEMC - 275HVD - HIGH VOLTAGE DETECTOR; 240 TO 275kV; LED

The AEMC 275HVD Non-Contact High Voltage Detector detects radiated electrical fields from about 10" (25 cm) away (and farther for lower voltage), is for use with hot sticks incorporating a universal spline adapter, and has an audible buzzer and bright red LED to indicate live voltage. The eight voltage sensitivity ranges, selected by rotary selector, are 240V, 2kV, 6kV, 11kV, 22kV, 33kV, 132kV, and 275kV. The self-test position ensures that circuitry, annunciators, and battery work before use. The detector is for use only with an insulated rod or hot stick rated at the appropriate working voltage and is not for use on shielded cables. It weighs 1.30 lbs. (0.59 kg) with batteries. The case measures 9" (229 mm) in height and 3.78" (98 mm) in width. Applications include identifying and checking live cables, checking and detecting live high voltage cables, finding faults in flexible cables, checking grounding equipment, servicing neon lighting, tracing live wires, checking high frequency radiation, and detecting residual or induced voltages.
