LXC200-1400SW Advanced Energy | Power Supplies - External/Internal (Off-Board) | DigiKey

Advanced Energy . LXC200-1400SW

Gallery

Attributes

Brand name, Manufacturer name, Manufacturer, MfrAdvanced Energy
Extra Product NameLXC200-1400SW Advanced Energy | Power Supplies - External/Internal (Off-Board) | DigiKey
atoms, minimum, moq, multiple, Number of Outputs1
MPNLXC200-1400SW
qtyInStock0
SKU633-1169-ND
Part Status, Dimming-
TypeConstant Current
TopologyAC DC Converter
Voltage - Input (Min)90VAC
Voltage - Input (Max)305VAC
Voltage - Output85 ~ 142V
Current - Output (Max)1.4A
FeaturesOTP, OVP, SCP
RatingsIP67
Operating Temperature-35?C ~ 70?C
Efficiency92%
Termination StyleWire Leads
Size / Dimension10.43" L x 3.13" W x 1.81" H (265.0mm x 79.5mm x 46.0mm)
Approval AgencyCE, cULus, EN
Mounting TypeChassis Mount
Weight3.2 lbs (1.5 kg)
Power (Watts)200 W
Voltage - Isolation3.75 kV

Distributor offers

SellerSKUMOQIn stockMultiplePrices
Digi-Key633-1169-ND11
Digi-Key267718711
ballastshop.comBS14-LXC200-1400SW111 @ $100.37
