Burndy 518581 Copper Compression Lug, 2 Hole YAV28L2TC38FXYEL. ✅Burndy authorized distributor ✅. ☎ (800) 884-5767 Mon-Fri 8:00 AM - 5:00 PM ET or order online 24/7

Burndy . YAV28L2TC38FXYEL

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBurndy
DimensionUnitinch
diameter, height, length0.56
height_Attrib, length_AttribDimension - Outside Diameter inch
moq, multiple1
MPN, SKUYAV28L2TC38FXYEL
qtyInStock0
snippetBurndy 518581 Copper Compression Lug, 2 Hole YAV28L2TC38FXYEL. ✅Burndy authorized distributor ✅. ☎ (800) 884-5767 Mon-Fri 8:00 AM - 5:00 PM ET or order online 24/7
width0.76
width_AttribDimension - Pad Width inch
Color CodePink
Connector TypeTerminal
Die Index19
Feature - Barrel StyleChamfered
Feature - Barrel TypeStandard
MaterialCopper
Physical Attribute - Number of Holes2
PlatedY
Plating TypeTin - Electro Plated
Dimension - B Length fraction11/16 in
Dimension - B Length inch0.69 in
Dimension - Bolt Hole Size inch0.39 in
Dimension - D inch0.83 in
Dimension - L Length Overall mm49 mm
Dimension - Length Overall inch1.94 in
Dimension - N inch0.41 in
Dimension - Outside Diameter inch0.56 in
Dimension - Pad Width inch0.76 in
Dimension - Strip Length inch11/16
Dimension - Stud Size inch3/8
Dimension - Z inch0.42 in
Physical Attribute - Tongue AngleStraight
Rating - KVA35 kV
Rating - Minimum Voltage600
Voltage - Maximum35000
Conductor - Copper DLO Size, Conductor - Copper DLO Size Range4/0 (275/#24) DLO
Conductor - Copper Flex G Size, Conductor - Copper Flex G Size Range, Conductor - Copper Flex H Size, Conductor - Copper Flex H Size Range, Conductor - Copper Flex I Size, Conductor - Copper Flex I Size Range, Conductor - Copper Flex K Size, Conductor - Copper Flex K Size Range, Conductor - Copper Flex M Size, Conductor - Copper Flex M Size Range4/0 AWG
Certification - CSA Approved, UL ListedYes
Certification - UL Recognized, Certification - cULusNo
Standards - RoHS Compliance StatusCM

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MegadepotYAV28L2TC38FXYEL11
gordonelectricsupply.comYAV28L2TC38FXYEL1-211 @ $242.10
usmegastore.comYAV28L2TC38FXYEL1-211 @ $23.50
Platt.com209915711
GalcoYAV28L2TC38FXYEL-BURN10101 @ $31.68
alldataresource.comYAV28L2TC38FXYEL1-211 @ $8.73
