Burndy . YA444NDTS

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBurndy
DimensionUnitinch
diameter, height, length1.5
height_Attrib, length_AttribDimension - Outside Diameter inch
moq, multiple1
MPN, SKUYA444NDTS
qtyInStock0
snippetBurndy 10066600 Cu Compression Lug, 4 Hole, 1000 Kcmil YA444NDTS. ✅$50 OFF Orders over $1499 ✅. Save Now! ☎ (800) 884-5767 Mon-Fri 8:00 AM - 5:00 PM ET or order online 24/7
width3.0
width_AttribDimension - Pad Width inch
Color CodeWhite
Connector TypeTerminal
Die Index27
Feature - Barrel StyleChamfered
Feature - Barrel Type, Physical Attribute - Tongue TypeStandard
Item Type3C
MaterialCopper
Physical Attribute - Number of Holes4
PlatedY
Plating TypeTin - Electro Plated
Temperature Rating194
Trade NameHYLUG™
Dimension - B Length fraction3 in
Dimension - B Length inch, Dimension - Pad Width inch3.00 in
Dimension - Bolt Hole Size inch0.52 in
Dimension - Bolt Size fraction, Dimension - Thread Size1/2
Dimension - D inch3.02 in
Dimension - F Width Center to Center inch1.75 in
Dimension - Hole Size inch0.56 in
Dimension - Hole Size mm14 mm
Dimension - L Length Overall mm181 mm
Dimension - Length Overall inch7.14 in
Dimension - N inch0.63 in
Dimension - Outside Diameter inch1.50 in
Dimension - Strip Length inch3-1/16
Dimension - Z inch0.64 in
Physical Attribute - Tongue AngleStraight
Rating - KVA35 kV
Rating - Minimum Voltage600
Voltage - Maximum35000
Conductor - Copper DLO Size RangeN/A
Conductor - Copper Str Size, Conductor - Copper Str Size Range1000 kcmil
Certification - CSA Approved, UL ListedYes
Certification - UL Recognized, Certification - cULusNo
Standards - RoHS Compliance StatusCM

Distributor offers

SellerSKUMOQIn stockMultiplePrices
MegadepotYA444NDTS11
usmegastore.comYA444NDTS1-211 @ $420.50
Platt.com209954311
GalcoYA444NDTS-BURN12121 @ $536.75
