Burndy . YA38L2TC38

Burndy . YA38L2TC38

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerBurndy
moq, multiple1
MPN, SKUYA38L2TC38
qtyInStockContact Us
Color CodePink
Connector TypeTerminal
Die Index400
Feature - Barrel Type, Physical Attribute - Tongue TypeStandard
Material, Conductor - MaterialCopper
Physical Attribute - Number of Holes2
PlatedY
Plating TypeTin - Electro Plated
Trade NameHYLUG™
TypeStandard Barrel, Tin Plated
Dimension - B Length fraction1-7/16 in
Dimension - B Length inch1.45 in
Dimension - Bolt Hole Size inch0.39 in
Dimension - Bolt Size fraction, Dimension - Stud Size inch3/8
Dimension - Hole Size inch0.40 in
Dimension - Hole Size mm10 mm
Dimension - L Length Overall mm110 mm
Dimension - Length Overall inch4.35 in
Dimension - N inch0.50 in
Dimension - Outside Diameter inch1.25 in
Dimension - Pad Width inch1.84 in
Dimension - Strip Length inch1-15/16
Dimension - Z inch0.52 in
Physical Attribute - Tongue AngleStraight
Rating - KVA35 kV
Rating - Minimum Voltage600
Voltage - Maximum35000
Conductor - Copper DLO Size RangeN/A
Conductor - Copper Str Size700 kcmil
Certification - CSA Approved, UL ListedYes
Certification - UL Recognized, Certification - cULusNo
Industry Standard(s)UL468A-468B
Standards - RoHS Compliance StatusCM
