HAHN BV UI 303 0143 | Transformer: encapsulated; 6VA; 115VACx2; 18V; 18V; 166mA; 166mA

HAHN . BV UI 303 0143

Gallery

Attributes

Brand name, Manufacturer name, ManufacturerHAHN
CategoryL1Transformers and Ferrite Cores
CategoryL2PCB transformers
Extra Product NameHAHN BV UI 303 0143 | Transformer: encapsulated; 6VA; 115VACx2; 18V; 18V; 166mA; 166mA
atoms, moq, multiple, tierMinQty11
jsonUrlData2576d4fe1441174faafd3e0f7cf9c798.
jsonUrlData2881a443f0e9b1e0b2273
keywordsHAHN, BV UI 303 0143, BVUI3030143, Transformers and Ferrite Cores, PCB transformers
MPNBV UI 303 0143
qtyInStock194
SKUBVUI3030143
snippetHAHN BV UI 303 0143 | Transformer: encapsulated; 6VA; 115VACx2; 18V; 18V; 166mA; 166m
tierMinQty220
tierMinQty3100
tierPrice19.65
tierPrice28.93
tierPrice38.45
Type of transformerencapsulated
Power6VA
Primary voltage115V AC x2
Secondary voltage 1, Secondary voltage 218V
Secondary winding current 1, Secondary winding current 2166mA
MountingPCB
Conform to the normPN EN 61558-2-6:2000
Thermal classTa70C/B
Body dimensions53.4x44.6x22.8mm
Manufacturer seriesBVUI

Distributor offers

SellerSKUMOQIn stockMultiplePrices
TMEBVUI3030143119411 @ $9.65, 20 @ $8.93, 100 @ $8.45
