SRU1063A-101Y Bourns Inc. | Inductors, Coils, Chokes | DigiKey

Bourns Inc. . SRU1063A-101Y

Attributes

Brand name, Manufacturer name, Manufacturer, MfrBourns Inc.
DimensionUnitinch
Extra Product NameSRU1063A-101Y Bourns Inc. | Inductors, Coils, Chokes | DigiKey
atoms, moq, multiple, tierMinQty11
extraShipping0
height0.268
height_AttribHeight - Seated (Max)
MPNSRU1063A-101Y
qtyInStock819
SKU6155177
snippet100 ?H Shielded Drum Core, Wirewound Inductor 1.1 A 320mOhm Max 4-SMD
tierMinQty105,000
tierMinQty210
tierMinQty325
tierMinQty450
tierMinQty5100
tierMinQty6250
tierMinQty92,500
tierPrice11.45000
tierPrice100.56565
tierPrice21.34800
tierPrice31.24440
tierPrice41.03700
tierPrice50.97480
tierPrice60.87112
tierPrice90.58450
CategoryInductors, Coils, Chokes
Series, Base Product NumberSRU1063A
PackageTape & Reel (TR)
Product StatusActive
TypeDrum Core, Wirewound
Material - CoreFerrite
Inductance100 ?H
Tolerance?30%
Current Rating (Amps)1.1 A
Current - Saturation (Isat)1.2A
ShieldingShielded
DC Resistance (DCR)320mOhm Max
Q @ Freq12 @ 796kHz
Frequency - Self Resonant4MHz
RatingsAEC-Q200
Operating Temperature-40?C ~ 125?C
Inductance Frequency - Test100 kHz
Mounting TypeSurface Mount
Package / Case4-SMD
Size / Dimension0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max)0.268" (6.80mm)

Distributor offers

SellerSKUMOQIn stockMultiplePrices
Digi-Key6155177181911 @ $1.45, 10 @ $1.35, 25 @ $1.24, 50 @ $1.04, 100 @ $0.97, 250 @ $0.87
Allied Electronics70912990500500
Newark96Y9757176911 @ $1.30, 10 @ $1.10, 25 @ $1.02, 50 @ $0.93, 100 @ $0.85
RS Online1356082105001010 @ $0.66
RS Delivers135-608211
iodPartsSRU1063A-101Y500500500500 @ $0.75
Digi-Key6155307181911 @ $1.45, 10 @ $1.35, 25 @ $1.24, 50 @ $1.04, 100 @ $0.97, 250 @ $0.87, 500 @ $0.68, 1000 @ $0.60, 2500 @ $0.58, 5000 @ $0.57
